Sony SA-CT770 - Power Cord (AC1); POWER Board

HT-CT770
16
2-14. POWER CORD (AC1)
2-15. POWER BOARD
1 connector
(CN901)
5 Draw out the power cord
from the hole.
6 power cord
(AC1)
2 Remove the cord bushing (FBS001)
in the direction of the arrow.
4 cord bushing (FBS001)
3 claw
1 screw
(BVTT3 u 6)
1 screw
(BVTT3 u 6)
1 two screws
(BVTT3 u 6)
2 Remove the POWER board block
in the direction of the arrow.
4 POWER board
3 cushion (H)
