Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT770
71
0 D942 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D965 6-501-849-01 DIODE FMX-22SL
D967 6-503-978-01 DIODE RB068L100TE25
0 D972 6-502-264-01 DIODE KDZTR18B
D973 8-719-083-71 DIODE UDZSUSTE-1730B
< FUSE >
0 F901 1-523-067-51 FUSE (5 A/250 V)
0 F931 1-523-085-11 FUSE (2.5 A/250 V)
< IC >
0 IC930 6-716-855-01 IC STR-Y6766 (Except US, CND, TW)
0 IC930 6-720-460-01 IC STR-Y6735 (US, CND, TW)
IC931 6-716-865-01 IC MM1431FNRE
< COIL >
L966 1-460-612-11 COIL, CHOKE 2.2uH
L967 1-481-175-21 INDUCTOR 4.7uH
< LINE FILTER >
0 LF901 1-445-944-11 TRANSFORMER, LINE FILTER
(Except US, CND, TW)
0 LF901 1-460-693-11 LINE FILTER TRANSFORMER (US, CND, TW)
< PHOTO COUPLER >
0 PH930 6-600-883-01 PHOTO COUPLER EL816S1 (B) (TA) (DTE-S)
< TRANSISTOR >
0 Q930 8-729-056-46 TRANSISTOR 2SC5053T100Q
0* Q931 6-553-105-01 TRANSISTOR PDTC144EU
Q950 6-550-586-01 TRANSISTOR 2PA1576R-115
(Except US, CND, TW)
* Q952 6-553-105-01 TRANSISTOR PDTC144EU
(Except US, CND, TW)
< RESISTOR >
0 R901 1-240-938-51 METAL 1.5M 5% 0.5W F
0 R914 1-248-270-15 FUSIBLE 0.33 10% 1W F
0 R932 1-216-345-51 METAL OXIDE 0.47 5% 1W F
(US, CND, TW)
0 R932 1-216-353-51 METAL OXIDE 2.2 5% 1W F
(Except US, CND, TW)
0 R934 1-248-050-11 METAL 0.22 5% 2W F
(Except US, CND, TW)
0 R934 1-248-245-11 METAL 0.15 5% 2W F
(US, CND, TW)
0 R935 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
0 R936 1-216-841-91 METAL CHIP 47K 5% 1/10W
0 R937 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R938 1-216-838-91 METAL CHIP 27K 5% 1/10W
0 R944 1-215-927-51 METAL OXIDE 47K 5% 3W F
(US, CND, TW)
0 R944 1-215-929-51 METAL OXIDE 100K 5% 3W F
(Except US, CND, TW)
0 R945 1-216-809-91 METAL CHIP 100 5% 1/10W
0 R947 1-216-793-91 METAL CHIP 4.7 5% 1/10W
R951 1-216-849-11 METAL CHIP 220K 5% 1/10W
(Except US, CND, TW)
R952 1-216-821-11 METAL CHIP 1K 5% 1/10W
(Except US, CND, TW)
R965 1-216-821-11 METAL CHIP 1K 5% 1/10W
R971 1-216-849-11 METAL CHIP 220K 5% 1/10W
R976 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R977 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R978 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R987 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R997 1-216-864-91 SHORT CHIP 0 (US, CND, TW)
0 R1009 1-216-793-91 METAL CHIP 4.7 5% 1/10W
0 R1010 1-216-793-91 METAL CHIP 4.7 5% 1/10W
0 R1011 1-216-864-91 SHORT CHIP 0
< TRANSFORMER >
0 T901 1-697-326-11 CONVERTER TRANSFORMER (01C327)
(Except US, CND, TW)
0 T901 1-697-327-11 CONVERTER TRANSFORMER (01C313)
(US, CND, TW)
< THERMISTOR >
0 TH901 1-811-315-31 POWER THERMISTOR
TH902 1-812-011-11 THERMISTOR, POSITIVE (Except US, CND, TW)
< VARISTOR >
0 VDR901 1-811-165-31 VARISTOR (TVR10471-D)
*************************************************************
MISCELLANEOUS
**************
0 AC1 1-834-966-41 POWER-SUPPLY CORD (AEP, SP)
0 AC1 1-835-068-21 CORD, POWER (AUS)
0 AC1 1-837-308-11 CORD, POWER-SUPPLY (US, CND)
0 AC1 1-837-345-11 CORD, POWER-SUPPLY
(TW)
0 AC1 1-837-822-21 CORD, POWER-SUPPLY (CH)
0 AC1 1-839-999-21 POWER-SUPPLY CORD (UK, EA)
BT1 1-490-558-92 BLUETOOTH MODULE
FFC1 9-885-194-85 FFC 19P HDMI-MAIN
FFC2 9-885-194-84 FFC 14P BT-MAIN
FFC3 9-885-194-82 FFC 24P TX-MAIN
FFC4 9-885-194-81 FFC 24P DISPLAY-MAIN
FFC5 9-885-194-86 FFC 8P NFC-MAIN
NFC1 8-989-470-05 RC-S801 (NFC module)
RF1 1-492-347-11 RF MODULATOR (SWA12-4V TX)
SP1 1-858-969-11 LOUDSPEAKER (6 cm) (Woofer) (L-ch)
SP2 1-858-969-11 LOUDSPEAKER (6 cm) (Woofer) (R-ch)
SP3 X-2589-422-1 TW ASSY (Tweeter) (L-ch)
SP4 X-2589-422-1 TW ASSY (Tweeter) (R-ch)
SPC1 1-848-071-12 CONNECTION CABLE WITH SPEAKER (L-ch)
SPC2 1-848-071-22 CONNECTION CABLE WITH SPEAKER (R-ch)
*************************************************************
Ver. 1.1
POWER
