Sony SA-WCT770 - SUB AMP SECTION

30
SA-WCT770
5-2. SUB AMP SECTION
51 3-077-331-71 +BV3 (3-CR)
52 4-237-065-01 CLAMP (L35)
53 A-1979-523-A POWER BOARD, COMPLETE (US, CND, TW)
53 A-1989-270-A POWER BOARD, COMPLETE
(Except US, CND, TW)
54 A-1979-519-A SUB MAIN BOARD, COMPLETE (See Note)
55 3-077-331-11 +BV3 (3-CR)
56 4-485-625-01 BUTTON
0 57 4-966-267-12 BUSHING (FBS001), CORD
58 4-974-510-11 SCREW (+BV 3X8 CU)
0 AC1 1-834-965-22 CORD, POWER (US, CND)
0 AC1 1-834-966-41 POWER-SUPPLY CORD (AEP, SP)
0 AC1 1-835-068-21 CORD, POWER (AUS)
0 AC1 1-837-345-11 CORD, POWER-SUPPLY (TW)
0 AC1 1-837-822-21 CORD, POWER-SUPPLY (CH)
0 AC1 1-839-999-21 POWER-SUPPLY CORD (UK, EA)
0 F900 1-533-453-12 FUSE, GLASS (DIA. 5) (5 A/125 V) (US, CND)
0 F900 1-576-230-51 FUSE (T 3.15 AH/ 250 V) (Except US, CND, TW)
0 F900 1-576-232-51 FUSE (H. B. C.) (T 5 AH/250 V) (TW)
FFC1 9-885-194-87 FFC 24P RX-SUB MAIN 77
RF1 1-492-348-11 RF MODULATOR (SWA12-4V RX)
#3 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C
D
B
B
D
C
C
not supplied
not supplied
not supplied
51
#3
#3
AC1
57
51
51
51
51
51
not supplied
not supplied
not supplied
55
55
F900
52
51
51
(Except US, CND)
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
51
51
51
51
not supplied
51
58
51
51
51
51
51
58
51
51
51
53
not supplied
not supplied
not supplied
not supplied
not supplied
RF1
FFC1
not
supplied
not
supplied
not supplied
not supplied
not supplied
not supplied
not supplied
(SUB KEY board)
not supplied
not supplied
not supplied
not supplied
56
54
51
Note: When the complete SUB MAIN board is replaced, refer to “NOTE
OF REPLACING THE IC104 ON THE SUB MAIN BOARD
AND THE COMPLETE SUB MAIN BOARD” on page 4.
