UFOELK - 2/21/2018 5:23 PM
33
HT-RT3
SECTION 7
ELECTRICAL PARTS LIST
When indicating parts by reference num-
ber, please include the board name.
Note:
Due to standardization, replacements in
the parts list may be different from the
parts speci ed in the diagrams or the com-
ponents used on the set.
-XX and -X mean standardized parts, so
they may have some difference from the
original one.
Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal- lm resistor.
METAL OXIDE: Metal oxide- lm resistor.
F: non ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
E12 : 220-240 V AC area in E model
EA : Saudi Arabia model
LA9 : Latin-American model
SP : Singapore model
MAINCONNECTOR
SPEAKER CHUKEI PC BOAROLED CHUKEI PC BOAR
The components identi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number speci ed.
Les composants identi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spéci é.
The components identi ed by mark 9 con-
tain con dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identi és par la marque
9 contiennent des informations con denti-
elles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
CONNECTOR BOARD
*****************
< CONNECTOR >
CN5008 1-842-052-21 CONNECTOR, FFC/FPC (LIF) 20P
CN5009 1-793-331-31 CONNECTOR, FFC/FPC (LIF) 20P
*************************************************************
9 A-2107-088-A MAIN BOARD, COMPLETE (for SERVICE)
(US, CND)
9 A-2107-150-A MAIN BOARD, COMPLETE (for SERVICE) (AEP)
9 A-2107-159-A MAIN BOARD, COMPLETE (for SERVICE) (UK)
9 A-2107-210-A MAIN BOARD, COMPLETE (for SERVICE) (E12)
9 A-2107-762-A MAIN BOARD, COMPLETE (for SERVICE) (AUS)
9 A-2107-776-A MAIN BOARD, COMPLETE (for SERVICE) (SP)
9 A-2107-842-A MAIN BOARD, COMPLETE (for SERVICE) (LA9)
9 A-2107-983-A MAIN BOARD, COMPLETE (for SERVICE) (AR)
9 A-2119-853-A MAIN BOARD, COMPLETE (for SERVICE) (EA)
*********************
< DIODE >
D3200 6-503-735-01 DI BZT52H-C4V3
< IC >
IC1000 6-721-742-01 IC TAS5614LA
IC1001 6-718-103-01 IC TAS5538DGGR
IC1002 6-721-742-01 IC TAS5614LA
IC2003 6-722-554-01 IC CXD90040R-B (MAIN board Suf x-12)
IC2005 6-720-801-01 IC EM638165TSD-6G
IC2009 6-722-554-01 IC CXD90040R-B (MAIN board Suf x-13)
IC3000 6-720-030-01 IC TPS2065CDBVR
IC3001 6-722-615-01 IC TC7WHU04FK,RSNJ (CT
IC3200 6-718-999-01 IC MM1839A50NRE
IC3201 6-721-694-01 IC RT7272BGSP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC3204 6-720-509-01 IC BD00IC0WHFV-GTR
< COIL >
L3207 1-246-226-11 METAL CHIP 15 0.5% 1/8W
< TRANSISTOR >
Q3208 6-553-482-01 TR SSM3J56MFV
*************************************************************
OLED CHUKEI PC BOAR BOARD
**************************
< CAPACITOR >
C5008 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
< CONNECTOR >
CN5002 1-843-407-31 FPC CONNECTOR (ZIF) (11PIN)
CN5003 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
CN5004 1-842-052-21 CONNECTOR, FFC/FPC (LIF) 20P
CN5005 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
< DIODE >
D5000 6-503-196-01 DI CL-194S-HB8SP-SD-T
< IC >
IC5001 6-600-629-01 IC RS-470
*************************************************************
SPEAKER CHUKEI PC BOAR BOARD
*****************************
< TRANSFORMER >
TB6000 1-780-454-11 TERMINAL BOARD (SPEAKER) 4P
TB6001 1-780-815-11 TERMINAL BOARD (SPEAKER)
*************************************************************
Note 1: When the complete MAIN board is replaced, re-
fer to “NOTE OF REPLACING THE IC1000 AND
IC1002 ON THE MAIN BOARD AND THE COM-
PLETE MAIN BOARD” on page 5.
Note 2: When the complete MAIN board is replaced,
spread the bond referring to“BOND FIXATION OF
ELECTRIC PARTS” on page 6.
Ver. 1.5
