SCD-XE800
SECTION 6
ELECTRICAL PARTS LIST
A-1775-568-A DISPLAY BOARD, COMPLETE
***********************
*
4-945-292-01 HOLDER, INDICATION TUBE
4-949-935-41 CUSHION (FL)
< CAPACITOR >
C803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C804 1-126-157-11 ELECT 10uF 20% 16V
C806 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C807 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C808 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C809 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C810 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C811 1-126-157-11 ELECT 10uF 20% 16V
C812 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C813 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C814 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C815 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C816 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C817 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C818 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN803 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D801 6-502-961-01 DIODE DA2J10100L
D802 8-719-046-41 LED SEL5521C-TP15 (
B
)
D803 8-719-046-39 LED SEL5821A-TP15 (
X
)
< IC >
IC801 6-600-767-01 IC PNA4823M02S0
IC802 6-705-899-01 IC ML9208-03MBZ03B
IC803 6-702-302-01 IC TK11133CSCL-G
< FLUORESCENT INDICATOR TUBE >
ND801 1-483-035-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q802 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q803 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q804 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R804 1-216-805-11 METAL CHIP 47 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R810 1-216-821-11 METAL CHIP 1K 5% 1/10W
R811 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-821-11 METAL CHIP 1K 5% 1/10W
R814 1-216-821-11 METAL CHIP 1K 5% 1/10W
R815 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R816 1-216-815-11 METAL CHIP 330 5% 1/10W
R817 1-216-817-11 METAL CHIP 470 5% 1/10W
< ROTARY ENCODER >
S806 1-477-995-11 ENCODER, ROTARY
(
.
AMS
>
PUSH ENTER)
< SWITCH >
S807 1-771-410-21 SWITCH, TACTILE (
Z
)
S808 1-771-410-21 SWITCH, TACTILE (
B
)
S809 1-771-410-21 SWITCH, TACTILE (
X
)
S810 1-771-410-21 SWITCH, TACTILE (
x
)
************************************************************
KEY BOARD
*********
< CONNECTOR >
CN809 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R801 1-216-821-11 METAL CHIP 1K 5% 1/10W
R802 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R803 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S801 1-771-410-21 SWITCH, TACTILE (l/
1
)
S802 1-771-410-21 SWITCH, TACTILE (SA-CD/CD)
S803 1-771-410-21 SWITCH, TACTILE (TIME/TEXT
S804 1-771-410-21 SWITCH, TACTILE (DISPLAY MODE)
************************************************************
A-1775-565-A MAIN BOARD, COMPLETE
********************
< CAPACITOR >
C201 1-115-156-11 CERAMIC CHIP 1uF 10V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY MAINDISPLAY
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
To Next Page
