Sony SDM-N50 - B Board Removal

SDM-N50
2-2
2-3. B BOARD REMOVAL
CN507
CN504
CN502
CN501
CN508
A
2
Remove the rear cover after move it in
the direction of allow A and also remove
concavities.
1
Three screws
(Tapping screw 3 x 8)
Four concavities
9
Screw
(0 plate special head)
4
Shield case (B)
10
B board
LCD module (TFT)
Cushion
Four claws
3
Three screws
(0 plate special head)
8
BH1 harness assembly
5
Two screws
(+P 2 x 4)
6
Cable holder (B)
7
Cable holder (A)
