SERVICE MANUAL
SPECIFICATIONS
MICROFILM
CHASSIS
US Model
Canadian Model
AEP Model
Chassis No. SCC-L32A-A
TFT LCD COLOR COMPUTER DISPLAY
SDM-N50
LCD panel Panel type: a-Si TFT Active Matrix
Picture size: 15 inch (38 cm)
Input signal format RGB operating frequency*
Horizontal: 30 – 61 kHz
Vertical: 50 – 85 Hz
Resolution Horizontal: Max.1024 dots
Vertical: Max.768 lines
Input signal levels RGB video signal
0.700 Vp-p, 75 Ω, positive
SYNC signal
TTL level, 2 kΩ,
positive or negative
(Separate horizontal and vertical,
or composite sync)
0.3 Vp-p, 75Ω, negative
(Sync on green)
Audio output 2W × 2
Headphones jack Stereo minijack
Accepts impedance of 16 – 48Ω
AUDIO IN jack Stereo minijack
Accepts impedance of 16 kΩ
Accepts level 0.5 Vrms
Power requirements 100 – 240 V, 50 – 60 Hz, 0.55 – 0.3 A
Power consumption Max. 35 W
Operating temperature 5 – 35
˚
C
Dimensions (width/height/depth)
Display (upright):
Approx. 356 × 347 × 185 mm
(14
1
/
8
× 13
3
/
4
× 7
3
/
8
inches)
Media engine (without stand):
Approx. 45 × 180 × 180 mm
(1
13
/
16
× 7
1
/
8
× 7
1
/
8
inches)
Media engine (with stand):
Approx. 94 × 185 × 180 mm
(3
3
/
4
× 7
3
/
8
× 7
1
/
8
inches)
Mass Display:
Approx. 2.7 kg (5 lb 15 oz)
Media engine (with stand):
Approx. 0.85 kg (1 lb 14 oz)
Plug & Play DDC1/DDC2B/DDC2Bi
Accessories • LCD display
• Media engine
• Media engine stand
• Power cord
• System connecting cable (2 m)
(applicable cable type: DP-2)
• HD15 (RGB) video signal cable
• Audio cord (stereo miniplug)
• Macintosh adapter
• Windows Monitor Information Disk/
Utility Disk
• Macintosh Utility Disk
• Warranty card
• Notes for Macintosh users
• This instruction manual
Recommended horizontal and vertical timing condition
• Horizontal sync width duty should be more than 4.8% of total
horizontal time or 0.8 µs, whichever is larger.
• Horizontal blanking width should be more than 2.3 µsec.
• Vertical blanking width should be more than 450 µsec.
Design and specifications are subject to change without notice.
