7-10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-366
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
C364 1-126-163-11 ELECT 4.7uF 20% 50V
C371 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C372 1-126-157-11 ELECT 10uF 20% 16V
C373 1-137-360-11 MYLAR 220PF 5% 50V
(EXCEPT CA30/GA35/SA33)
C374 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(EXCEPT CA30/GA35/SA33)
C375 1-137-374-11 MYLAR 0.047uF 5% 50V
(EXCEPT CA30/GA35/SA33)
C376 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
(EXCEPT CA30/GA35/SA33)
C377 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(GA65)
C377 1-164-232-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT CA30/GA35/SA33/GA65)
C378 1-124-589-11 ELECT 47uF 20% 16V
(EXCEPT CA30/GA35/SA33)
C379 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(EXCEPT CA30/GA35/SA33)
C380 1-124-589-11 ELECT 47uF 20% 16V
C381 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C382 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
(EXCEPT CA30/GA35/SA33)
0 C601 1-104-705-11 MYLAR 0.1uF 20% 250V
0 C602 1-104-705-11 MYLAR 0.1uF 20% 250V
0 C603 1-113-898-11 CERAMIC 330PF 10% 250V
0 C604 1-113-898-11 CERAMIC 330PF 10% 250V
0 C605 1-113-898-11 CERAMIC 330PF 10% 250V
0 C606 1-107-405-11 ELECT (BLOCK) 68uF 20% 400V
C607 1-107-925-11 ELECT 1uF 20% 100V
C608 1-136-160-00 MYLAR 0.039uF 5% 50V
C609 1-107-974-11 CERAMIC 47PF 5% 2KV
C610 1-136-203-11 MYLAR 0.01uF 10% 400V
C611 1-104-683-11 MYLAR 0.0047uF 5% 50V
C612 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C613 1-126-160-11 ELECT 1uF 20% 50V
C614 1-126-926-11 ELECT 1000uF 20% 10V
C615 1-126-767-11 ELECT 1000uF 20% 16V
C616 1-126-941-11 ELECT 470uF 20% 25V
C617 1-126-935-11 ELECT 470uF 20% 16V
C618 1-124-589-11 ELECT 47uF 20% 16V
C619 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C620 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C621 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C626 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C627 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C628 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C630 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C901 1-124-589-11 ELECT 47uF 20% 16V
C902 1-126-160-11 ELECT 1uF 20% 50V
(EXCEPT CA30/GA35/SA33)
C903 1-128-057-11 ELECT 330uF 20% 6.3V
C906 1-124-589-11 ELECT 47uF 20% 16V
C907 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN001 1-695-330-31 HOUSING, CONNECTOR 7P
* CN031 1-766-716-11 CONNECTOR, BOARD TO BOARD 3P
CN051 1-779-723-11 CONNECTOR, BOARD TO BOARD 9P
CN201 1-691-040-41 HOUSING, CONNECTOR 8P
* CN202 1-560-892-00 PIN, CONNECTOR 4P
* CN331 1-568-955-11 PIN, CONNECTOR 6P (EXCEPT GA65)
* CN331 1-573-129-11 PIN, CONNECTOR 6P (GA65)
CN332 1-506-468-11 PIN, CONNECTOR 3P
(EXCEPT CA30/GA35/SA33)
CN401 1-784-486-11 CONNECTOR, FFC/FPC 7P
0 CN601 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
(EXCEPT GA65)
CN601 1-774-108-11 PIN, CONNECTOR (PC BOARD) (GA65)
< DIODE >
D001 8-719-048-26 DIODE GL528V1 (T/S. LED)
D101 8-719-911-19 DIODE 1SS119-25TD
D401 8-719-056-07 DIODE SLR-342MCT31 (ON/STANDBY)
D402 8-719-045-62 DIODE SLR-342VCT31 (ON/STANDBY)
(EXCEPT CA30/GA35: PL, TW/
GA55PL/GF85: PL, TW/SA33)
D403 8-719-056-07 DIODE SLR-342MCT31 (DANCE 1)
D404 8-719-056-07 DIODE SLR-342MCT31 (DANCE 2)
D405 8-719-056-07 DIODE SLR-342MCT31 (DANCE 4)
D406 8-719-056-07 DIODE SLR-342MCT31 (DANCE 3)
D407 8-719-056-07 DIODE SLR-342MCT31 (TAPE INSIDE)
D408 8-719-045-62 DIODE SLR-342VCT31 (z REC)
(EXCEPT CA30/GA35/SA33)
D409 8-719-056-07 DIODE SLR-342MCT31 (L) (GF85/SP100)
D410 8-719-056-07 DIODE SLR-342MCT31 (HiFi) (GF85/SP100)
D411 8-719-056-07 DIODE SLR-342MCT31 (R) (GF85/SP100)
D412 8-719-056-07 DIODE SLR-342MCT31 (VIDEO)
(CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
D413 8-719-045-62 DIODE SLR-342VCT31 (SYNCHRO REC)
(EXCEPT CA30/GA35/SA33)
0 D601 8-719-051-93 DIODE DF06M-6031
D602 8-719-109-89 DIODE RD5.6ES-T1B2
D603 8-719-110-47 DIODE RD18ES-T1B (EXCEPT GA65)
D603 8-719-113-37 DIODE RD18ES-T2B (GA65)
D604 8-719-054-32 DIODE ERA15-06TP3
D605 8-719-911-19 DIODE 1SS119-25TD
D606 8-719-911-19 DIODE 1SS119-25TD
D607 8-719-109-59 DIODE RD2.7ES-T1B1
D608 8-719-030-25 DIODE EG01CV0 (EXCEPT GA65)
D608 8-719-030-33 DIODE EG01CV1 (GA65)
D609 8-719-911-19 DIODE 1SS119-25TD
D610 8-719-022-97 DIODE D2S4MF
D611 8-719-073-18 DIODE S3L20UF34
D612 8-719-110-18 DIODE RD10ES-T1B3
D613 8-719-160-64 DIODE RD16F-T8B1
D901 8-719-108-12 DIODE RD9.1EW-T1 (GF85/SP100)
D902 8-719-108-12 DIODE RD9.1EW-T1 (GF85/SP100)
< EARTH TERMINAL >
ET001 1-537-770-21 TERMINAL, EARTH
< FUSE >
0 F601 1-532-388-31 FUSE (2.0A/250V)
To Next Page
