7-11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
MA-366
< FUSE HOLDER >
FH601 1-533-223-11 HOLDER, FUSE
FH602 1-533-223-11 HOLDER, FUSE
< IC >
IC031 8-759-481-46 IC LB1943
IC101 8-759-599-42 IC HD6433975RA-CPAF
IC102 8-759-248-87 IC MM1256XF-BE
0 IC103 8-759-991-41 IC L78L05ACZ-AP
IC201 8-759-589-31 IC HA118217F
(EXCEPT CA30/GA35: PL, TW/
GA55PL/GF85: PL, TW/SA33)
IC201 8-759-589-32 IC HA118217NF
(CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
IC301 8-759-638-56 IC TDA9605H/N2, 557 (GF85/SP100)
0 IC601 8-759-321-95 IC HA17431PA-TZ
< JACK >
* J901 1-779-924-11 JACK, PIN 2P (LINE-1 OUT)
(CA30/GA35/SA33)
J901 1-779-010-11 JACK, PIN 4P (LINE-1 IN/OUT)
(GA55/GA65/SP70)
J901 1-779-011-11 JACK, PIN 6P (LINE-1 IN/OUT) (GF85/SP100)
< JUMPER RESISTOR >
JR002 1-216-295-00 METAL CHIP 0 5% 1/10W
JR003 1-216-295-00 METAL CHIP 0 5% 1/10W
JR004 1-216-295-00 METAL CHIP 0 5% 1/10W
JR005 1-216-295-00 METAL CHIP 0 5% 1/10W
JR007 1-216-295-00 METAL CHIP 0 5% 1/10W
JR008 1-216-295-00 METAL CHIP 0 5% 1/10W
JR009 1-216-295-00 METAL CHIP 0 5% 1/10W
JR010 1-216-295-00 METAL CHIP 0 5% 1/10W
JR011 1-216-295-00 METAL CHIP 0 5% 1/10W
JR012 1-216-295-00 METAL CHIP 0 5% 1/10W
JR013 1-216-295-00 METAL CHIP 0 5% 1/10W
JR014 1-216-295-00 METAL CHIP 0 5% 1/10W
JR100 1-216-296-00 METAL CHIP 0 5% 1/8W
JR101 1-216-296-00 METAL CHIP 0 5% 1/8W
JR102 1-216-296-00 METAL CHIP 0 5% 1/8W
JR103 1-216-296-00 METAL CHIP 0 5% 1/8W
JR104 1-216-296-00 METAL CHIP 0 5% 1/8W
JR105 1-216-296-00 METAL CHIP 0 5% 1/8W
JR107 1-216-296-00 METAL CHIP 0 5% 1/8W
JR108 1-216-296-00 METAL CHIP 0 5% 1/8W
JR109 1-216-296-00 METAL CHIP 0 5% 1/8W
JR110 1-216-296-00 METAL CHIP 0 5% 1/8W
JR111 1-216-296-00 METAL CHIP 0 5% 1/8W
JR112 1-216-296-00 METAL CHIP 0 5% 1/8W
JR113 1-216-296-00 METAL CHIP 0 5% 1/8W
JR114 1-216-296-00 METAL CHIP 0 5% 1/8W
JS371 1-216-295-00 METAL CHIP 0 5% 1/10W
(CA30/GA35/SA33)
JS372 1-216-295-00 METAL CHIP 0 5% 1/10W
(EXCEPT GF85/SP100)
< COIL >
L101 1-410-511-11 INDUCTOR 15uH
L201 1-414-857-51 INDUCTOR 100uH
L202 1-414-151-31 INDUCTOR 470uH (EXCEPT GA65)
L202 1-414-151-21 INDUCTOR 470uH (GA65)
L203 1-414-857-51 INDUCTOR 100uH
L204 1-410-510-11 INDUCTOR 12uH
L205 1-410-520-11 INDUCTOR 82uH
L206 1-414-857-51 INDUCTOR 100uH
L207 1-414-857-51 INDUCTOR 100uH
L208 1-410-519-11 INDUCTOR 68uH
L210 1-414-856-51 INDUCTOR 10uH
L261 1-410-513-11 INDUCTOR 22uH
(EXCEPT GF85: PL, TW)
L262 1-410-503-11 INDUCTOR 3.3uH
L301 1-414-857-51 INDUCTOR 100uH (GF85/SP100)
L302 1-414-856-51 INDUCTOR 10uH (GF85/SP100)
L351 1-414-857-51 INDUCTOR 100uH
L371 1-414-857-51 INDUCTOR 100uH
(EXCEPT CA30/GA35/SA33)
L372 1-414-187-11 INDUCTOR 47uH
(EXCEPT CA30/GA35/SA33)
L601 1-410-858-21 INDUCTOR 0uH
L602 1-412-529-11 INDUCTOR 22uH
L603 1-412-529-11 INDUCTOR 22uH
L901 1-414-857-51 INDUCTOR 100uH
< LINE FILTER >
LF601 1-416-929-11 FILTER, LINE
< PHOTO INTERRUPTER >
PH001 8-749-013-23 PHOTO INTERRUPTER GP3S120 (T REEL)
PH002 8-749-013-23 PHOTO INTERRUPTER GP3S120 (S REEL)
0 PH601 8-749-010-65 PHOTO COUPLER PC123FY2
< IC LINK >
0 PS601 1-533-588-31 LINK, IC (0.5A)
0 PS602 1-533-590-31 LINK, IC (1.0A)
< TRANSISTOR >
Q001 8-729-042-88 TRANSISTOR RPT-37PBT32 (T SENS)
Q002 8-729-042-88 TRANSISTOR RPT-37PBT32 (S SENS)
Q003 8-729-106-68 TRANSISTOR 2SD1664-T100-R
Q201 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
Q202 8-729-421-19 TRANSISTOR UN2213-TX
Q203 8-729-421-19 TRANSISTOR UN2213-TX
(EXCEPT CA30/GA35: PL, TW/
GA55PL/GF85: PL, TW/SA33)
Q204 8-729-421-19 TRANSISTOR UN2213-TX
Q205 8-729-216-21 TRANSISTOR 2SA1162Y-TE85L
Q261 8-729-421-19 TRANSISTOR UN2213-TX
Q262 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
Q263 8-729-421-19 TRANSISTOR UN2213-TX
Q264 8-729-216-21 TRANSISTOR 2SA1162Y-TE85L
Q265 8-729-230-49 TRANSISTOR 2SC2712L-TE85L
(EXCEPT GF85: PL, TW)
Q266 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
Q267 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
To Next Page
