7-12
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-366
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
Q290 8-729-421-19 TRANSISTOR UN2213-TX
Q291 8-729-421-19 TRANSISTOR UN2213-TX
Q292 8-729-421-19 TRANSISTOR UN2213-TX
Q293 8-729-421-19 TRANSISTOR UN2213-TX
Q294 8-729-043-69 TRANSISTOR UN2225- (TX). S0
Q295 8-729-043-69 TRANSISTOR UN2225- (TX). S0
Q296 8-729-421-19 TRANSISTOR UN2213-TX
Q297 8-729-421-19 TRANSISTOR UN2213-TX
Q298 8-729-043-69 TRANSISTOR UN2225- (TX). S0
Q299 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
Q371 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
Q372 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
(EXCEPT CA30/GA35/SA33)
Q373 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
(EXCEPT CA30/GA35/SA33)
Q374 8-729-424-18 TRANSISTOR UN2113-TX
(EXCEPT CA30/GA35/SA33)
Q375 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
(EXCEPT CA30/GA35/SA33)
Q376 8-729-424-56 TRANSISTOR UN211L-TX
(EXCEPT CA30/GA35/SA33)
Q377 8-729-421-19 TRANSISTOR UN2213-TX
(EXCEPT CA30/GA35/SA33)
Q378 8-729-421-19 TRANSISTOR UN2213-TX
(EXCEPT CA30/GA35/SA33)
Q401 8-729-421-19 TRANSISTOR UN2213-TX
Q402 8-729-421-19 TRANSISTOR UN2213-TX
(EXCEPT CA30/GA35/SA33)
Q403 8-729-421-19 TRANSISTOR UN2213-TX (GF85/SP100)
Q404 8-729-421-19 TRANSISTOR UN2213-TX (GF85/SP100)
Q405 8-729-421-19 TRANSISTOR UN2213-TX (GF85/SP100)
Q406 8-729-421-19 TRANSISTOR UN2213-TX
(CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
Q407 8-729-421-19 TRANSISTOR UN2213-TX
(EXCEPT CA30/GA35/SA33)
Q408 8-729-421-19 TRANSISTOR UN2213-TX
Q601 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
Q602 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q603 8-729-043-47 TRANSISTOR 2SK2671
0 Q604 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q901 8-729-216-21 TRANSISTOR 2SA1162Y-TE85L
< RESISTOR >
R001 1-247-815-91 CARBON 220 5% 1/4W
(EXCEPT GA65)
R001 1-249-409-11 CARBON 220 5% 1/4W
(GA65)
R002 1-247-815-91 CARBON 220 5% 1/4W
(EXCEPT GA65)
R002 1-249-409-11 CARBON 220 5% 1/4W
(GA65)
R003 1-249-421-11 CARBON 2.2K 5% 1/4W
R004 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R005 1-247-807-31 CARBON 100 5% 1/4W
R006 1-247-807-31 CARBON 100 5% 1/4W
R007 1-216-049-00 METAL CHIP 1K 5% 1/10W
R008 1-216-049-00 METAL CHIP 1K 5% 1/10W
R009 1-216-073-00 METAL CHIP 10K 5% 1/10W
R031 1-247-863-91 CARBON 22K 5% 1/4W
(EXCEPT GA65)
R031 1-249-433-11 CARBON 22K 5% 1/4W
(GA65)
R032 1-216-089-00 METAL CHIP 47K 5% 1/10W
R033 1-216-077-91 RES, CHIP 15K 5% 1/10W
R051 1-216-222-00 RES, CHIP 10K 5% 1/8W
R052 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R053 1-216-073-00 METAL CHIP 10K 5% 1/10W
R054 1-216-073-00 METAL CHIP 10K 5% 1/10W
R055 1-216-037-00 METAL CHIP 330 5% 1/10W
R056 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R101 1-216-170-00 RES, CHIP 68 5% 1/8W
R102 1-249-403-11 CARBON 68 5% 1/4W
R103 1-216-021-00 METAL CHIP 68 5% 1/10W
R104 1-216-021-00 METAL CHIP 68 5% 1/10W
R105 1-216-105-91 RES, CHIP 220K 5% 1/10W
R106 1-249-435-11 CARBON 33K 5% 1/4W
R107 1-247-863-91 CARBON 22K 5% 1/4W
(EXCEPT GA65)
R107 1-249-433-11 CARBON 22K 5% 1/4W
(GA65)
R108 1-249-437-11 CARBON 47K 5% 1/4W
R109 1-216-222-00 RES, CHIP 10K 5% 1/8W
R110 1-216-222-00 RES, CHIP 10K 5% 1/8W
R111 1-216-073-00 METAL CHIP 10K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
R113 1-216-085-00 METAL CHIP 33K 5% 1/10W
R114 1-216-099-00 METAL CHIP 120K 5% 1/10W
R115 1-216-049-00 METAL CHIP 1K 5% 1/10W
R116 1-216-121-91 RES, CHIP 1M 5% 1/10W
R117 1-216-049-00 METAL CHIP 1K 5% 1/10W
R118 1-247-895-00 CARBON 470K 5% 1/4W
R119 1-216-001-00 METAL CHIP 10 5% 1/10W
R120 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R121 1-216-049-00 METAL CHIP 1K 5% 1/10W
R122 1-216-121-91 RES, CHIP 1M 5% 1/10W
R123 1-216-121-91 RES, CHIP 1M 5% 1/10W
R124 1-216-073-00 METAL CHIP 10K 5% 1/10W
R125 1-216-081-00 METAL CHIP 22K 5% 1/10W
R126 1-216-081-00 METAL CHIP 22K 5% 1/10W
R127 1-216-073-00 METAL CHIP 10K 5% 1/10W
R128 1-216-073-00 METAL CHIP 10K 5% 1/10W
R129 1-216-081-00 METAL CHIP 22K 5% 1/10W
R130 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R131 1-216-238-91 RES, CHIP 47K 5% 1/8W
R132 1-249-429-11 CARBON 10K 5% 1/4W
R133 1-247-863-91 CARBON 22K 5% 1/4W
(GF85/SP100)
R134 1-249-437-11 CARBON 47K 5% 1/4W
R135 1-249-429-11 CARBON 10K 5% 1/4W
R136 1-247-831-91 CARBON 1K 5% 1/4W
(EXCEPT GA65)
R136 1-249-417-11 CARBON 1K 5% 1/4W
(GA65)
R137 1-247-831-91 CARBON 1K 5% 1/4W
(EXCEPT GA65)
R137 1-249-417-11 CARBON 1K 5% 1/4W
(GA65)
