8-15
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
! PS601 1-533-586-31 LINK, IC (315mA)
< TRANSISTOR >
Q100 8-729-043-84 TRANSISTOR PT380F3
Q101 8-729-043-84 TRANSISTOR PT380F3
Q102 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q161 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q191 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
(ED40/ED70/EZ70)
Q201 8-729-421-19 TRANSISTOR UN2213-TX
Q202 8-729-421-19 TRANSISTOR UN2213-TX
Q203 8-729-421-19 TRANSISTOR UN2213-TX
Q206 8-729-421-19 TRANSISTOR UN2213-TX
Q330 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
(ED40/ED70/EZ70)
Q331 8-729-900-51 TRANSISTOR UN2115-QRS (TX)
(ED40/ED70/EZ70)
Q332 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q333 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q334 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q335 8-729-900-51 TRANSISTOR UN2115-QRS (TX)
Q337 8-729-424-18 TRANSISTOR UN2113-TX
Q338 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q400 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q401 8-729-421-19 TRANSISTOR UN2213-TX
Q402 8-729-421-22 TRANSISTOR UN2211-TX
Q403 8-729-421-22 TRANSISTOR UN2211-TX
Q410 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q701 8-729-106-68 TRANSISTOR 2SD1664-T100-R
Q702 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX (ED70/EZ70)
Q901 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
< RESISTOR >
R100 1-249-437-11 CARBON 47K 5% 1/4W
R101 1-216-041-00 METAL CHIP 470 5% 1/10W
R102 1-249-437-11 CARBON 47K 5% 1/4W
R103 1-216-085-00 METAL CHIP 33K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R106 1-249-417-11 CARBON 1K 5% 1/4W
R107 1-249-400-11 CARBON 39 5% 1/4W
R108 1-249-400-11 CARBON 39 5% 1/4W
R110 1-249-429-11 CARBON 10K 5% 1/4W
R111 1-216-073-00 METAL CHIP 10K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
R113 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R114 1-216-049-00 METAL CHIP 1K 5% 1/10W
R115 1-216-049-00 METAL CHIP 1K 5% 1/10W
R116 1-216-103-00 METAL CHIP 180K 5% 1/10W
R117 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R118 1-216-049-00 METAL CHIP 1K 5% 1/10W
R119 1-216-103-00 METAL CHIP 180K 5% 1/10W
R120 1-216-049-00 METAL CHIP 1K 5% 1/10W
R121 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R122 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R130 1-216-085-00 METAL CHIP 33K 5% 1/10W
R131 1-216-085-00 METAL CHIP 33K 5% 1/10W
R132 1-216-089-00 METAL CHIP 47K 5% 1/10W
R160 1-216-041-00 METAL CHIP 470 5% 1/10W
R161 1-216-073-00 METAL CHIP 10K 5% 1/10W
R162 1-216-049-00 METAL CHIP 1K 5% 1/10W
R163 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R164 1-216-073-00 METAL CHIP 10K 5% 1/10W
R165 1-216-049-00 METAL CHIP 1K 5% 1/10W
R166 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(ED10/EZ40)
R166 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(ED40/EZ60)
R166 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(ED60/EZ70: AS)
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
(ED70/EZ70: NZ)
R166 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(EZ10)
R167 1-216-073-00 METAL CHIP 10K 5% 1/10W
R168 1-247-863-91 CARBON 22K 5% 1/4W
R169 1-216-049-00 METAL CHIP 1K 5% 1/10W
R170 1-216-121-91 RES, CHIP 1M 5% 1/10W
R171 1-216-049-00 METAL CHIP 1K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-073-00 METAL CHIP 10K 5% 1/10W
R174 1-216-073-00 METAL CHIP 10K 5% 1/10W
R175 1-216-113-00 METAL CHIP 470K 5% 1/10W
R176 1-216-089-00 METAL CHIP 47K 5% 1/10W
R177 1-216-105-91 RES, CHIP 220K 5% 1/10W
R178 1-216-089-00 METAL CHIP 47K 5% 1/10W
R179 1-216-089-00 METAL CHIP 47K 5% 1/10W
R180 1-216-089-00 METAL CHIP 47K 5% 1/10W
R181 1-216-041-00 METAL CHIP 470 5% 1/10W
R182 1-216-049-00 METAL CHIP 1K 5% 1/10W
R183 1-216-041-00 METAL CHIP 470 5% 1/10W
R184 1-216-073-00 METAL CHIP 10K 5% 1/10W
R185 1-216-073-00 METAL CHIP 10K 5% 1/10W
R186 1-249-417-11 CARBON 1K 5% 1/4W
R187 1-216-049-00 METAL CHIP 1K 5% 1/10W
R188 1-216-049-00 METAL CHIP 1K 5% 1/10W
R189 1-216-073-00 METAL CHIP 10K 5% 1/10W
R190 1-216-073-00 METAL CHIP 10K 5% 1/10W
R191 1-216-103-00 METAL CHIP 180K 5% 1/10W
R192 1-216-049-00 METAL CHIP 1K 5% 1/10W
R193 1-216-121-91 RES, CHIP 1M 5% 1/10W
R194 1-249-437-11 CARBON 47K 5% 1/4W
(ED40/ED70/EZ70)
R195 1-216-037-00 METAL CHIP 330 5% 1/10W
R196 1-216-037-00 METAL CHIP 330 5% 1/10W
R198 1-216-089-00 METAL CHIP 47K 5% 1/10W
R199 1-216-041-00 METAL CHIP 470 5% 1/10W
R201 1-216-041-00 METAL CHIP 470 5% 1/10W
R202 1-216-083-00 METAL CHIP 27K 5% 1/10W
R203 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R205 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R206 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R207 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(ED10/EZ10)
R207 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(ED40/ED60/ED70/EZ40/EZ60/EZ70)
MA-350
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
