– 2 –
SAFETY CHECK-OUT
1. Check the area of your repair for unsoldered or poorly-sol-
dered connections. Check the entire board surface for solder
splashes and bridges.
2. Check the interboard wiring to ensure that no wires are
“pinched” or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transis-
tors, that were installed during a previous repair. Point them
out to the customer and recommend their replacement.
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
4. Look for parts which, though functioning, show obvious signs
of deterioration. Point them out to the customer and recom-
mend their replacement.
5. Check the B+ voltage to see it is at the values specified.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED
LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
LINE –1 OUT
VIDEO OUT, phono jack (1)
Output signal: 1 Vp-p, 75 ohms, unbal-
anced, sync negative
AUDIO OUT, phono jack (2)
Standard output: 327 mVrms
Load impedance; 47 kilohms
Output impedance: less than 10 kilohms
LINE –2 OUT (AUDIO)
AUDIO OUT, phono jack (2)
Standard output: 327 mVrms
Load impedance; 47 kilohms
Output impedance: less than 10 kilohms
SKY TV DECODER (EZ8NZ)
VIDEO IN, phono jack (1)
Input signal: 1 Vp-p, 75 ohms, unbalanced,
sync negative
VIDEO OUT, phono jack (1)
Output signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
General
Power requirements
110 – 240 V AC, 50/60 Hz (ED8)
220-240 V AC, 50 Hz (EZ8/EZ9)
Power consumption
22W (ED8)
23W (EZ8/EZ9)
Operating temperature
5 ˚C to 40 ˚C
Storage temperature
–20 ˚C to 60 ˚C
Dimensions
Approx. 430 × 100 × 286 mm (w/h/d):
including projecting parts and controls
Mass
Approx. 5.7 kg: (ED8)
Approx. 5.9 kg: (EZ8/EZ9)
Supplied accessories
Remote commander (1)
R6 (size AA) batteries (2)
Aerial cable (1)
Plug adaptor (1) (ED8)
Audio/Video cable (3-phono to 3-phono) (1)
Design and specifications are subject to change
without notice.
SLV- ED8 EZ8 EZ8 EZ9
FEATURE AS NZ AS
ME-SECAM (REC/PB) ®/®G/GG/GG/G
ADDITIONAL REAR INPUT (SAT IN) ®GG®
SKY TV DECODER IN/OUT G/GG/G®/®G/G
MODULATOR SYSTEM G,K,I,M G G G
CLICK/JOG SHUTTLE (REMOTE COMMANDER) G/GG/GG/G®/®
REMOTE COMMANDER RMT- V245 V245 V245 V243
• Feature Difference
