SERVICE NOTE
1. DISASSEMBLY
• This set can be disassembled in the order shown below.
Note: Pages in indicated pages in the SERVICE MANUAL.
Pages in indicated pages in the VHS MECHANICAL ADJUSTMENT MANUAL VI.
NK-11 Board
(ED8/EZ8NZ)
(Page 2-1)
Set
Upper case
(Page 2-1)
Front Panel
Section
(Page 2-1)
Power
Block
(Page 2-3)
Rear Panel
(Page 2-1)
Pinch Press
Block Ass’y
(Page 14)
Ground Shaft
Ass’y
(Page 13)
Drum Ass’y
(Page 13)
RJ-79 Board
(Page 2-1)
Mechanism
Deck
(Page 2-2)
FR-137 Board
(Page 2-2)
FL complete
Ass’y
(Page 13)
FL Slider
Block Ass’y
(Page 22)
DM-77 Board
(Page 2-2)
SW-307 Board
(EZ9)
(Page 2-2)
Rubber
Belt
(Page 15)
IO-64 Board
(Page 2-2)
Retainer
Plate
(Page 22)
Rubber
Belt
(Page 15)
Capstan
Motor
(Page 15)
Control Switch
Block (EZ9)
(Page 2-2)
Rotary
Switch
(Page 2-2)
Tuner
Unit
Pully Gear
Ass’y
(Page 29)
Cam Gear
(Page 23)
Cam Motor
Retainer
(Page 31)
Rubber
Belt
(Page 15)
Reel Direct
Ass’y
(Page 30)
Slider
(Page 26)
Loading
Gear (T, S)
(Page 28)
Cam Motor
(Page 31)
MA-325 Board
(Page 2-3)
PS-414 Board
(Page 2-3)
