• Waveforms
1 IC161 ^• REC/PB
2 IC161 ^ª REC/PB
3 IC161 &º REC/PB
5 IC161 7 REC
6 IC161 $£ REC/PB
4 IC161 1 REC/PB
5.3 Vp-p (2 V)
5.0 Vp-p (300 Hz)
5.1 Vp-p (757.6 Hz)
5.1 Vp-p (2 V)
5.0 Vp-p (2 V)
2.4 Vp-p (16 MHz)
