8-8
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FR-137
C340 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(ED8/EZ8)
C341 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN302 1-691-036-21 HOUSING, CONNECTOR 4P (EZ9)
* CN303 1-695-352-11 PIN, CONNECTOR (PC BOARD) 29P
* CN307 1-691-406-11 CONNECTOR, BOARD TO BOARD 7P (ED8/EZ8)
CN308 1-784-484-11 CONNECTOR, FFC/FPC 5P (EZ9)
CN309 1-691-066-21 HOUSING, CONNECTOR 7P (EZ9)
< DIODE >
D307 8-719-109-93 DIODE RD6.2ES-B2
D308 8-719-950-60 DIODE MPG06D-6052PKG23
D309 8-719-950-60 DIODE MPG06D-6052PKG23
D311 8-719-017-09 DIODE 02DZ6.2-TPH3
D318 8-719-056-07 DIODE SLR-342MCT31 (ON/STANDBY)
(ED8/EZ8)
D319 8-719-017-09 DIODE 02DZ6.2-TPH3
< IC >
IC301 8-752-896-84 IC CXP82948-037Q (EZ8/EZ9)
IC301 8-752-896-55 IC CXP82948-036Q (ED8)
IC302 8-759-248-87 IC MM1256XF-BE
IC303 8-759-432-32 IC ST24W04FM6TR
IC304 8-749-011-05 IC GP1U28X (ED8/EZ8)
< JUMPER RESISTOR >
JR301 1-216-296-00 METAL CHIP 0 5% 1/8W
JR302 1-216-296-00 METAL CHIP 0 5% 1/8W
JR304 1-216-295-00 METAL CHIP 0 5% 1/10W
JR306 1-216-296-00 METAL CHIP 0 5% 1/8W
JR307 1-216-295-00 METAL CHIP 0 5% 1/10W
JR308 1-216-295-00 METAL CHIP 0 5% 1/10W
JR309 1-216-296-00 METAL CHIP 0 5% 1/8W
JR310 1-216-296-00 METAL CHIP 0 5% 1/8W
JR311 1-216-296-00 METAL CHIP 0 5% 1/8W
JR315 1-216-296-00 METAL CHIP 0 5% 1/8W
JR316 1-216-295-00 METAL CHIP 0 5% 1/10W
JR317 1-216-296-00 METAL CHIP 0 5% 1/8W
JR319 1-216-296-00 METAL CHIP 0 5% 1/8W
JR320 1-216-295-00 METAL CHIP 0 5% 1/10W
JR321 1-216-296-00 METAL CHIP 0 5% 1/8W
JR322 1-216-296-00 METAL CHIP 0 5% 1/8W
< COIL >
L301 1-414-938-21 INDUCTOR 47uH
L302 1-414-938-21 INDUCTOR 47uH (EZ9)
L303 1-414-932-21 INDUCTOR 4.7uH
L304 1-414-932-21 INDUCTOR 4.7uH
< FLUORECENT INDICATOR >
ND320 1-517-734-31 TUBE, FLUORESCENT INDICATOR (EZ9)
ND320 1-517-734-21 TUBE, FLUORESCENT INDICATOR (ED8/EZ8)
< TRANSISTOR >
Q300 8-729-421-22 TRANSISTOR UN2211 (ED8/EZ8)
< RESISTOR >
R301 1-216-025-91 RES,CHIP 100 5% 1/10W
R302 1-216-295-00 METAL CHIP 0 5% 1/10W
R303 1-249-417-11 CARBON 1K 5% 1/4W
R304 1-216-049-00 METAL CHIP 1K 5% 1/10W
R305 1-216-049-00 METAL CHIP 1K 5% 1/10W
R306 1-216-089-00 METAL CHIP 47K 5% 1/10W
R307 1-216-049-00 METAL CHIP 1K 5% 1/10W
R308 1-216-113-00 METAL CHIP 470K 5% 1/10W
R309 1-216-073-00 METAL CHIP 10K 5% 1/10W
R310 1-216-073-00 METAL CHIP 10K 5% 1/10W
R311 1-216-295-00 METAL CHIP 0 5% 1/10W
R312 1-216-198-91 RES,CHIP 1K 5% 1/8W
R313 1-249-417-11 CARBON 1K 5% 1/4W
R314 1-216-073-00 METAL CHIP 10K 5% 1/10W
R315 1-216-095-00 METAL CHIP 82K 5% 1/10W
R316 1-216-041-00 METAL CHIP 470 5% 1/10W
R317 1-247-807-31 CARBON 100 5% 1/4W
R318 1-247-807-31 CARBON 100 5% 1/4W
R319 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R320 1-216-041-00 METAL CHIP 470 5% 1/10W
R321 1-216-025-91 RES,CHIP 100 5% 1/10W
R322 1-216-025-91 RES,CHIP 100 5% 1/10W
R323 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R324 1-249-417-11 CARBON 1K 5% 1/4W
R325 1-216-049-00 METAL CHIP 1K 5% 1/10W
R326 1-216-049-00 METAL CHIP 1K 5% 1/10W
R327 1-216-095-00 METAL CHIP 82K 5% 1/10W
R328 1-216-113-00 METAL CHIP 470K 5% 1/10W
R329 1-216-190-00 RES,CHIP 470 5% 1/8W
(EZ9)
R329 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED8/EZ8)
R334 1-216-073-00 METAL CHIP 10K 5% 1/10W
R337 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED8/EZ8)
R338 1-216-029-00 METAL CHIP 150 5% 1/10W
(ED8/EZ8)
R340 1-216-682-11 METAL CHIP 20K 0.5% 1/10W
(ED8/EZ8)
R341 1-208-812-11 RES,CHIP 18K 0.50% 1/10W
(ED8/EZ8)
R342 1-216-083-00 METAL CHIP 27K 5% 1/10W
(ED8/EZ8)
R343 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
(ED8/EZ8)
R347 1-216-095-00 METAL CHIP 82K 5% 1/10W
< SWITCH >
S300 1-762-196-21 SWITCH, TACT (ON/STANDBY) (ED8/EZ8)
S301 1-762-196-21 SWITCH, TACT (PROGRAM-) (ED8/EZ8)
S302 1-762-196-21 SWITCH, TACT (SP/LP/EP) (ED8/EZ8)
S303 1-762-196-21 SWITCH, TACT (PROGRAM+) (ED8/EZ8)
S304 1-762-196-21 SWITCH, TACT (COLOR SYSTEM) (ED8/EZ8)
S305 1-762-196-21 SWITCH, TACT (ONE TOUCH TUNING)
(ED8/EZ8)
S306 1-762-196-21 SWITCH, TACT (EASY TIMER) (ED8/EZ8)
S309 1-762-196-21 SWITCH, TACT (EJECT)
< VIBRATOR >
X301 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X302 1-579-930-12 VIBRATOR, CERAMIC (16MHz)
