Sony SNC-WR632C User Manual

3-1 (E)
SNC-WR632C/WR602C
Section 3
Troubleshooting
3-1. Operation Check
In case that the alert of fan is displayed
When an abnormality occurs in the cooling fan inside of this unit, the alert is notified in the following
ways. Check if there is any abnormality in the cooling fan inside of this unit immediately.
. FAN ALARM is displayed on the viewer screen.
(It disappears after a specified period of time.)
. A mail to notify the abnormality of fan is delivered to the registered administrator of this unit.
Does this unit start?
No
No
Yes
Does this unit perform the
initial operation?
(Detection of Pan/Tilt original
potion)
Yes
Go to “3-2. Power Trouble”.
Go to “3-3. Pan/Tilt Trouble”.
No
Is the image output from VBS
OUT?
Yes
Go to “3-4. Image Trouble”.
No
Can this unit be recognized by
using SNC toolbox, etc. via the
network?
Yes
Go to “3-5. Network Trouble”.
No
Is the image output on the
PC monitor?
Yes
Go to “3-4. Image Trouble”.
No
Do the sensor input/output,
serial communication, AUDIO,
and card slot operate correctly?
Yes
Turn on the power.
Normal operation
Is there any problem with FFC
connecting between CN105 on
the SY-416 board and CN704 on
the IF-1232 board, or with the
connection of FFC?
No
Yes
Replace the SY-416 board.
(Refer to Section 1-4-6.)
FFC: flexible flat cable
Replace FFC, or connect FFC
correctly.

Sony SNC-WR632C Specifications

General

Type	IP security camera
PTZ control	Yes
PTZ protocols	Pelco-D
Languages support	ARA, CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, HIN, ITA, JPN, KOR, POL, POR, RUS, THA, TUR
Placement supported	Outdoor
Light exposure modes	Auto, Manual, Shutter priority AE
Connectivity technology	Wired
IK code	IK10
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Pan range	0 - 360 °
White balance	ATW, Fluorescent, Indoor, Manual, One push, Outdoor, Sodium lamp
Tilt angle range	0 - 220 °
Angle of rotation	360 °
Camera shutter speed	1/1 - 1/10000 s
Minimum illumination	0.018 lx
Audio formats supported	AAC, G.711, G.726
Signal-to-Noise Ratio (SNR)	50 dB
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	30 x
Focal length range	4.3 - 129 mm
Maximum aperture number	4.7
Minimum aperture number	1.6
Closest focusing distance	0.3 m
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Total megapixels	2.38 MP
Gain control type	Auto/Manual
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Supported graphics resolutions	352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 720 x 480, 720 x 576, 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Compatible memory cards	SD
Maximum memory card size	64 GB
Number of users	20 user(s)
Streaming method	Multicast
Networking standards	IEEE 802.1x
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, DNS, NTP, RTP/RTCP, RTSP over TCP, RTSP over HTTP, SMTP, IPv6, HTTPS, FTP (client), SNMP (v1, v2c, v3), SSL
Cables included	AC, BNC
Behavior analysis	Intrusion detection, Object removal detection
Intelligent Video Surveillance (IVS) system features	Face detection, Intrusion, Missing object
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
AC input voltage	24 V
Power source type	AC, PoE
Power consumption (max)	80 W
Power consumption (Power over Ethernet (PoE))	55 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-40 - 50 °C
Storage relative humidity (H-H)	20 - 95 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Height	324.1 mm
Weight	4100 g
Diameter	222 mm
