3-2 (E)
SNC-WR632C/WR602C
3-2. Power Trouble
No
No
Does the fans*1 (2 pcs)
connected to the HC-51 board
operate correctly?
Yes
Yes
Is a voltage of 24 V output from
pin 3, and is a voltage of 5 V
output from pins 4 and 5 of
CN2501 on the PS-858 board?
No
Yes
When you short pins 10 and 9
of CN2003 on the PS-858 board,
is a voltage output from pins
3 to 5 of CN2501?
No
No
Is a voltage of 5 V output from
pins 4 and 5, while a voltage of
24 V is not output from pin 3 of
CN2501 on the PS-858 board?
Yes
No
Does a voltage at pin 8 of
CN2501 on the PS-858 board
become 3.3 V a little later after
the power is turned on?
Yes
Replace the SY-416 board.
(Refer to Section 1-4-6.)
Replace the HC-51 board.
(Refer to Section 1-4-5.)
Replace the PS-858 board.
(Refer to Section 1-4-5.)
Replace the SY-416 board.
(Refer to Section 1-4-6.)
Replace the PS-858 board.
(Refer to Section 1-4-5.)
Is a voltage input to pins 1
and 2 of CN5002 on the HC-51
board?
Check the connection between
CN5002 on the HC-51 board and
CN702 on the IF-1232 board.
Check F801 on the TM-61 board.
Check if the power is steadily input to
the TM-61 board
Yes
Replace the HC-51 board.
(Refer to Section 1-4-5.)
No
Is a voltage of 24 VAC input to
pins 1 to 4 of CN1003 on the
PS-858 board?
Yes
Check the connection between
CN5001 on the HC-51 board and
CN1003 on the PS-858 board.
To Next Page
