20
GB
Note on speaker cords
The connector of the speaker cords are color-
coded based on the speaker type. When
connecting a speaker cord, be sure to match
the colored connector to the speaker terminal
on the receiver.
*HT-M7 only.
To connect the speakers
correctly
Check the speaker type by referring to the
speaker label* on the rear panel of the
speakers.
*The center speaker and subwoofers do not have
any character on the speaker label. For details on
the speaker type, see page 2.
** HT-M7 only.
Connector Speaker terminal
Purple SUBWOOFER
White FRONT L
Red FRONT R
Blue SURROUND L
Grey SURROUND R
Brown SURROUND BACK L
*
Tan SURROUND BACK R*
Green CENTER
Character on
speaker label
Speaker type
L Front left
R Front right
SL Surround left
SR Surround right
SBL
** Surround back left
SBR
** Surround back right
