This receiver incorporates Dolby* Digital and Pro
Logic Surround and the DTS** Digital Surround
System.
* Manufactured under license from Dolby
Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
**“DTS” and “DTS Digital Surround” are registered
trademarks of Digital Theater Systems, Inc.
About This Manual
• The instructions in this manual are for model
STR-DB780. Check your model number by looking
at the lower right corner of the front panel. In this
manual, the models of area code U is used for
illustration purposes unless stated otherwise. Any
difference in operation is clearly indicated in the
text, for example, “Models of area code U only”.
• The instructions in this manual describe the controls
on the receiver. You can also use the controls on the
supplied remote if they have the same or similar
names as those on the receiver. For details on the
use of your remote:
– Models of area code U, CA
RM-PP506L: See the separate operating
instructions supplied with the remote.
– Models of other area codes
RM-U305C: See pages 53–56.
About area codes
The area code of the receiver you purchased is
shown on the lower portion of the rear panel (see
the illustration below).
Any differences in operation, according to the
area code, are clearly indicated in the text, for
example, “Models of area code AA only”.
Area code
4-XXX-XXX-XX AA
SUB
WOOFER
AC OUTLET
PRE OUT
FRONT CENTER
SURROUND
OUT
R
L
I
MPEDANCE
SELECTOR
4 Ω 8 Ω
