– 54 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC107 8-759-267-86 IC SN74HC00ANS-E20 (DB825)
< COIL >
L101 1-410-509-11 INDUCTOR 10uH
L102 1-408-080-00 INDUCTOR 100uH (DB825)
< TRANSISTOR >
Q101 8-729-900-36 TRANSISTOR DTC124ES
Q102 8-729-900-63 TRANSISTOR DTA124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q104 8-729-900-36 TRANSISTOR DTC124ES
Q105 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q106 8-729-119-79 TRANSISTOR 2SC2785-FEK (DB825)
Q107 8-729-900-80 TRANSISTOR DTC114ES (DB825)
Q108 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q129 8-729-801-93 TRANSISTOR 2SD1387 (DB825)
Q130 8-729-801-93 TRANSISTOR 2SD1387 (DB825)
Q150 8-729-900-36 TRANSISTOR DTC124ES
Q413 8-729-900-80 TRANSISTOR DTC114ES
Q1101 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R101 1-249-429-11 CARBON 10K 5% 1/4W
R103 1-249-425-11 CARBON 4.7K 5% 1/4W F
R104 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-425-11 CARBON 4.7K 5% 1/4W F
R106 1-249-425-11 CARBON 4.7K 5% 1/4W F
R107 1-249-425-11 CARBON 4.7K 5% 1/4W F
R109 1-247-843-11 CARBON 3.3K 5% 1/4W
R110 1-247-843-11 CARBON 3.3K 5% 1/4W
R111 1-247-843-11 CARBON 3.3K 5% 1/4W
R112 1-249-417-11 CARBON 1K 5% 1/4W F
R113 1-249-441-11 CARBON 100K 5% 1/4W
R114 1-249-429-11 CARBON 10K 5% 1/4W
R115 1-247-807-31 CARBON 100 5% 1/4W
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-249-425-11 CARBON 4.7K 5% 1/4W F
R118 1-247-807-31 CARBON 100 5% 1/4W
R119 1-249-425-11 CARBON 4.7K 5% 1/4W F
R123 1-247-807-31 CARBON 100 5% 1/4W
R124 1-249-417-11 CARBON 1K 5% 1/4W F
R128 1-247-807-31 CARBON 100 5% 1/4W
R129 1-247-807-31 CARBON 100 5% 1/4W
R130 1-247-807-31 CARBON 100 5% 1/4W
R131 1-247-807-31 CARBON 100 5% 1/4W
R132 1-247-807-31 CARBON 100 5% 1/4W
R133 1-247-807-31 CARBON 100 5% 1/4W
R134 1-247-807-31 CARBON 100 5% 1/4W
R135 1-247-807-31 CARBON 100 5% 1/4W
R136 1-247-807-31 CARBON 100 5% 1/4W
R137 1-249-429-11 CARBON 10K 5% 1/4W
R138 1-247-807-31 CARBON 100 5% 1/4W
R139 1-247-807-31 CARBON 100 5% 1/4W
R140 1-247-807-31 CARBON 100 5% 1/4W
R142 1-247-807-31 CARBON 100 5% 1/4W
R143 1-247-807-31 CARBON 100 5% 1/4W
R144 1-247-807-31 CARBON 100 5% 1/4W
R146 1-249-383-11 CARBON 1.5 5% 1/6W F
(DB825)
R148 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DB825)
R150 1-249-409-11 CARBON 220 5% 1/4W
R152 1-249-411-11 CARBON 330 5% 1/4W
R153 1-249-411-11 CARBON 330 5% 1/4W
R154 1-249-411-11 CARBON 330 5% 1/4W
R155 1-249-429-11 CARBON 10K 5% 1/4W
R156 1-249-421-11 CARBON 2.2K 5% 1/4W F
R157 1-249-421-11 CARBON 2.2K 5% 1/4W F
R159 1-249-429-11 CARBON 10K 5% 1/4W
R160 1-249-429-11 CARBON 10K 5% 1/4W
R161 1-249-437-11 CARBON 47K 5% 1/4W
R162 1-249-433-11 CARBON 22K 5% 1/4W
R165 1-249-429-11 CARBON 10K 5% 1/4W
(DB825)
R167 1-249-385-00 CARBON 2.2 5% 1/4W F
(DB825)
R168 1-249-429-11 CARBON 10K 5% 1/4W
(DB825)
R171 1-249-429-11 CARBON 10K 5% 1/4W
(DB825)
R172 1-249-417-11 CARBON 1K 5% 1/4W F
R190 1-249-429-11 CARBON 10K 5% 1/4W
R1101 1-249-393-11 CARBON 10 5% 1/4W F
R1106 1-249-429-11 CARBON 10K 5% 1/4W
R1107 1-249-429-11 CARBON 10K 5% 1/4W
R1108 1-249-425-11 CARBON 4.7K 5% 1/4W F
R3000 1-249-385-11 CARBON 2.2 5% 1/4W F
RR10 1-247-843-11 CARBON 3.3K 5% 1/4W
RR11 1-249-409-11 CARBON 220 5% 1/4W F
RR12 1-249-411-11 CARBON 330 5% 1/4W
RR13 1-249-413-11 CARBON 470 5% 1/4W F
RR101 1-249-437-11 CARBON 47K 5% 1/4W
RR102 1-249-437-11 CARBON 47K 5% 1/4W
RR103 1-249-437-11 CARBON 47K 5% 1/4W
RR104 1-249-437-11 CARBON 47K 5% 1/4W
RR105 1-249-437-11 CARBON 47K 5% 1/4W
RR106 1-249-437-11 CARBON 47K 5% 1/4W
RR107 1-249-437-11 CARBON 47K 5% 1/4W
RR108 1-249-437-11 CARBON 47K 5% 1/4W
RR109 1-249-437-11 CARBON 47K 5% 1/4W
RR110 1-249-437-11 CARBON 47K 5% 1/4W
RR111 1-249-437-11 CARBON 47K 5% 1/4W
RR112 1-249-437-11 CARBON 47K 5% 1/4W
RR113 1-249-437-11 CARBON 47K 5% 1/4W
RR114 1-249-437-11 CARBON 47K 5% 1/4W
RR115 1-249-437-11 CARBON 47K 5% 1/4W
RR116 1-249-437-11 CARBON 47K 5% 1/4W
RR117 1-249-437-11 CARBON 47K 5% 1/4W
RR118 1-249-437-11 CARBON 47K 5% 1/4W
RR119 1-249-437-11 CARBON 47K 5% 1/4W
RR120 1-249-437-11 CARBON 47K 5% 1/4W
RR121 1-249-437-11 CARBON 47K 5% 1/4W
RR122 1-249-437-11 CARBON 47K 5% 1/4W
RR123 1-249-437-11 CARBON 47K 5% 1/4W
RR124 1-249-437-11 CARBON 47K 5% 1/4W
RR125 1-249-437-11 CARBON 47K 5% 1/4W
DISPLAY
