Sony STR-DB825 User Manual

– 55 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
H.P
RR126 1-249-437-11 CARBON 47K 5% 1/4W
RR127 1-249-437-11 CARBON 47K 5% 1/4W
RR128 1-249-437-11 CARBON 47K 5% 1/4W
RR129 1-249-437-11 CARBON 47K 5% 1/4W
< VIBRATOR >
X101 1-577-101-11 VIBRATOR, CERAMIC (4.19MHz)
X102 1-767-938-21 VIBRATOR, CERAMIC (7.28MHz)(DB825)
**************************************************************
* 1-670-099-11 FUNCTION BOARD
**************
< CONNECTOR >
CNS120 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
< DIODE >
D116 8-719-313-45 DIODE SEL6810A-TH10 (TUNING)
< RESISTOR >
R151 1-249-413-11 CARBON 470 5% 1/4W
RR154 1-249-411-11 CARBON 330 5% 1/4W
RR155 1-249-409-11 CARBON 220 5% 1/4W F
< VARIABLE RESISTOR >
RV101 1-467-808-11 ENCODER, ROTARY (FUNCTION)
< SWITCH >
S129 1-762-751-11 SWITCH, TACTILE (MUTING)
S130 1-762-751-11 SWITCH, TACTILE (MODE)
**************************************************************
* 1-669-443-11 H.P BOARD
*********
< JACK >
J701 1-568-519-41 JACK, LARGE TYPE (PHONES)
**************************************************************
* A-4414-176-A INPUT BOARD, COMPLETE
*********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C001 1-126-966-11 ELECT 33uF 20% 50V
C002 1-162-284-31 CERAMIC 150PF 10% 50V
C003 1-102-233-00 CERAMIC 33PF 10% 500V
C004 1-107-584-11 CERAMIC 4PF 0.25PF 500V
C005 1-126-934-11 ELECT 220uF 20% 10V
C006 1-162-282-31 CERAMIC 100PF 10% 50V
C050 1-126-934-11 ELECT 220uF 20% 10V
C051 1-126-966-11 ELECT 33uF 20% 50V
C052 1-162-284-31 CERAMIC 150PF 10% 50V
C053 1-102-233-00 CERAMIC 33PF 10% 500V
C054 1-107-584-11 CERAMIC 4PF 0.25PF 500V
C056 1-162-282-31 CERAMIC 100PF 10% 50V
C100 1-126-948-11 ELECT 100uF 20% 35V
C300 1-162-283-31 CERAMIC 120PF 10% 50V
C301 1-162-283-31 CERAMIC 120PF 10% 50V
C303 1-162-306-11 CERAMIC 0.01uF 20% 16V
C303 1-162-306-11 CERAMIC 0.01uF 20% 16V
C306 1-126-961-11 ELECT 2.2uF 20% 50V
C307 1-126-961-11 ELECT 2.2uF 20% 50V
C308 1-126-934-11 ELECT 220uF 20% 10V
C309 1-126-934-11 ELECT 220uF 20% 10V
C310 1-125-896-91 MYLAR 0.0091uF 5% 50V
C311 1-125-896-91 MYLAR 0.0091uF 5% 50V
C312 1-136-159-00 FILM 0.033uF 5% 50V
C313 1-136-159-00 FILM 0.033uF 5% 50V
C314 1-126-961-11 ELECT 2.2uF 20% 50V
C315 1-126-961-11 ELECT 2.2uF 20% 50V
C316 1-126-933-11 ELECT 100uF 20% 16V
C317 1-126-933-11 ELECT 100uF 20% 16V
C318 1-104-664-11 ELECT 47uF 20% 16V
C319 1-104-664-11 ELECT 47uF 20% 16V
C320 1-126-965-11 ELECT 22uF 20% 50V
C322 1-162-294-31 CERAMIC 0.001uF 10% 50V
C323 1-162-282-31 CERAMIC 100PF 10% 50V
C332 1-164-159-11 CERAMIC 0.1uF 50V
C333 1-164-159-11 CERAMIC 0.1uF 50V
C334 1-164-159-11 CERAMIC 0.1uF 50V
C335 1-164-159-11 CERAMIC 0.1uF 50V
C336 1-164-159-11 CERAMIC 0.1uF 50V
C337 1-164-159-11 CERAMIC 0.1uF 50V
C343 1-126-966-11 ELECT 33uF 20% 50V
C344 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C345 1-162-199-31 CERAMIC 10PF 5% 50V
C346 1-162-199-31 CERAMIC 10PF 5% 50V
C349 1-162-199-31 CERAMIC 10PF 5% 50V
C350 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C351 1-126-966-11 ELECT 33uF 20% 50V
C352 1-126-965-11 ELECT 22uF 20% 50V
C353 1-162-306-11 CERAMIC 0.01uF 20% 16V
C370 1-126-965-11 ELECT 22uF 20% 50V
C371 1-126-966-11 ELECT 33uF 20% 50V
C431 1-126-960-11 ELECT 1uF 20% 50V
C433 1-126-960-11 ELECT 1uF 20% 50V
C437 1-126-960-11 ELECT 1uF 20% 50V
C439 1-126-960-11 ELECT 1uF 20% 50V
C443 1-126-960-11 ELECT 1uF 20% 50V
C460 1-164-159-11 CERAMIC 0.1uF 50V
C462 1-126-934-11 ELECT 220uF 20% 16V
C463 1-164-159-11 CERAMIC 0.1uF 50V
C464 1-126-934-11 ELECT 220uF 20% 16V
C465 1-162-207-31 CERAMIC 22PF 5% 50V
C466 1-102-527-11 CERAMIC 82PF 5% 50V
C467 1-126-961-11 ELECT 2.2uF 20% 50V
C468 1-102-852-91 CERAMIC 47PF 5% 50V
C469 1-162-306-11 CERAMIC 0.01uF 20% 16V
C470 1-162-291-31 CERAMIC 560PF 10% 50V
C471 1-126-960-11 ELECT 1uF 20% 50V
C472 1-164-159-11 CERAMIC 0.1uF 50V
DISPLAY FUNCTION INPUT
