– 58 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
REAR AMP
R558 1-249-441-11 CARBON 100K 5% 1/4W
R559 1-247-903-00 CARBON 1M 5% 1/4W
R560 1-249-426-11 CARBON 5.6K 5% 1/4W
R561 1-249-434-11 CARBON 27K 5% 1/4W
R563 1-249-426-11 CARBON 5.6K 5% 1/4W
R564 1-249-418-11 CARBON 1.2K 5% 1/4W F
R565 1-249-441-11 CARBON 100K 5% 1/4W
R566 1-247-843-11 CARBON 3.3K 5% 1/4W
R567 1-247-883-00 CARBON 150K 5% 1/4W
R568 1-249-427-11 CARBON 6.8K 5% 1/4W F
R569 1-249-413-11 CARBON 470 5% 1/4W F
! R592 1-249-381-11 CARBON 1 5% 1/4W F
! R593 1-249-381-11 CARBON 1 5% 1/4W F
R595 1-247-903-00 CARBON 1M 5% 1/4W
R596 1-249-421-11 CARBON 2.2K 5% 1/4W F
R597 1-247-843-11 CARBON 3.3K 5% 1/4W
R598 1-249-421-11 CARBON 2.2K 5% 1/4W F
R599 1-247-843-11 CARBON 3.3K 5% 1/4W
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-249-437-11 CARBON 47K 5% 1/4W
R604 1-249-417-11 CARBON 1K 5% 1/4W F
R608 1-249-429-11 CARBON 10K 5% 1/4W
R609 1-249-434-11 CARBON 27K 5% 1/4W
R651 1-249-417-11 CARBON 1K 5% 1/4W F
R652 1-249-439-11 CARBON 68K 5% 1/4W
R653 1-249-437-11 CARBON 47K 5% 1/4W
R654 1-249-417-11 CARBON 1K 5% 1/4W F
R658 1-249-429-11 CARBON 10K 5% 1/4W
R659 1-249-434-11 CARBON 27K 5% 1/4W
R690 1-249-433-11 CARBON 22K 5% 1/4W
R694 1-249-425-11 CARBON 4.7K 5% 1/4W F
R699 1-249-437-11 CARBON 47K 5% 1/4W
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-247-876-11 CARBON 75K 5% 1/4W
R704 1-249-413-11 CARBON 470 5% 1/4W F
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-247-876-11 CARBON 75K 5% 1/4W
R754 1-249-413-11 CARBON 470 5% 1/4W F
R790 1-249-433-11 CARBON 22K 5% 1/4W
R3000 1-247-895-00 CARBON 470K 5% 1/4W
R3001 1-249-433-11 CARBON 22K 5% 1/4W
R3002 1-249-441-11 CARBON 100K 5% 1/4W
R3003 1-249-429-11 CARBON 10K 5% 1/4W
R3004 1-249-429-11 CARBON 10K 5% 1/4W
R3005 1-249-440-11 CARBON 82K 5% 1/4W
R3008 1-249-425-11 CARBON 4.7K 5% 1/4W F
R3009 1-249-441-11 CARBON 100K 5% 1/4W
R3010 1-247-852-11 CARBON 7.5K 5% 1/4W
R3011 1-249-413-11 CARBON 470 5% 1/4W F
R3012 1-249-429-11 CARBON 10K 5% 1/4W
R3013 1-249-429-11 CARBON 10K 5% 1/4W
R3014 1-249-429-11 CARBON 10K 5% 1/4W
R3060 1-247-852-11 CARBON 7.5K 5% 1/4W
R3062 1-249-429-11 CARBON 10K 5% 1/4W
R3063 1-249-429-11 CARBON 10K 5% 1/4W
R3368 1-247-903-00 CARBON 1M 5% 1/4W
R5002 1-249-429-11 CARBON 10K 5% 1/4W
R5052 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY301 1-515-614-11 RELAY
< VIBRATOR >
X450 1-579-900-21 VIBRATOR, CRYSTAL (4.33MHz)
**************************************************************
* A-4414-843-A REAR AMP BOARD, COMPLETE
************************
< CAPACITOR >
C720 1-104-664-11 ELECT 47uF 20% 16V
C721 1-107-597-11 CERAMIC 22PF 10% 500V
C722 1-107-597-11 CERAMIC 22PF 10% 500V
C723 1-162-286-31 CERAMIC 220PF 10% 50V
C725 1-136-157-00 FILM 0.022uF 5% 50V
C770 1-104-664-11 ELECT 47uF 20% 16V
C771 1-107-597-11 CERAMIC 22PF 10% 500V
C772 1-107-597-11 CERAMIC 22PF 10% 500V
C773 1-162-286-31 CERAMIC 220PF 10% 50V
C775 1-136-157-00 FILM 0.022uF 5% 50V
< CONNECTOR >
CNE711 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CNE713 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
* CNV711 1-564-241-11 PIN, CONNECTOR (B4P-VH) 4P
* CNV712 1-564-242-00 PIN, CONNECTOR 5P
< DIODE >
D701 8-719-911-19 DIODE 1SS119-25
D702 8-719-109-51 DIODE RD2.0ES-B2
D703 8-719-109-51 DIODE RD2.0ES-B2
D704 8-719-911-19 DIODE 1SS119-25
D751 8-719-911-19 DIODE 1SS119-25
D752 8-719-109-51 DIODE RD2.0ES-B2
D753 8-719-109-51 DIODE RD2.0ES-B2
D754 8-719-911-19 DIODE 1SS119-25
< TRANSISTOR >
Q704 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q705 8-729-209-15 TRANSISTOR 2SD2012
Q706 8-749-010-25 IC MN2488-OPY-M
Q707 8-749-010-26 IC MP1620-OPY-M
Q708 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q754 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q755 8-729-209-15 TRANSISTOR 2SD2012
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
Q758 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R706 1-247-881-00 CARBON 120K 5% 1/4W
R721 1-249-437-11 CARBON 47K 5% 1/4W
INPUT
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
