– 59 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SP
R722 1-249-429-11 CARBON 10K 5% 1/4W
R723 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R724 1-249-408-11 CARBON 180 5% 1/4W F
! R725 1-249-408-11 CARBON 180 5% 1/4W F
! R726 1-233-352-41 ENCAPSULATED COMPONENT
R727 1-247-850-11 CARBON 6.2K 5% 1/4W
R728 1-249-417-11 CARBON 1K 5% 1/4W F
R732 1-249-437-11 CARBON 47K 5% 1/4W
! R733 1-249-393-11 CARBON 10 5% 1/4W F
R756 1-247-881-00 CARBON 120K 5% 1/4W
R771 1-249-437-11 CARBON 47K 5% 1/4W
R772 1-249-429-11 CARBON 10K 5% 1/4W
R773 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R774 1-249-408-11 CARBON 180 5% 1/4W F
! R775 1-249-408-11 CARBON 180 5% 1/4W F
! R776 1-233-352-41 ENCAPSULATED COMPONENT
R777 1-247-850-11 CARBON 6.2K 5% 1/4W
R778 1-249-417-11 CARBON 1K 5% 1/4W F
R782 1-249-437-11 CARBON 47K 5% 1/4W
! R783 1-249-393-11 CARBON 10 5% 1/4W F
**************************************************************
* A-4407-581-A S VIDEO BOARD, COMPLETE
***********************
< CAPACITOR >
C251 1-126-960-11 ELECT 1uF 20% 50V
C252 1-136-165-00 FILM 0.1uF 5% 50V
C253 1-126-960-11 ELECT 1uF 20% 50V
C254 1-136-165-00 FILM 0.1uF 5% 50V
C255 1-136-165-00 FILM 0.1uF 5% 50V
C256 1-126-960-11 ELECT 1uF 20% 50V
C259 1-126-960-11 ELECT 1uF 20% 50V
C260 1-136-165-00 FILM 0.1uF 5% 50V
C262 1-164-159-11 CERAMIC 0.1uF 50V
C263 1-164-159-11 CERAMIC 0.1uF 50V
C265 1-164-159-11 CERAMIC 0.1uF 50V
C266 1-164-159-11 CERAMIC 0.1uF 50V
C267 1-162-215-31 CERAMIC 47PF 5% 50V
C268 1-162-215-31 CERAMIC 47PF 5% 50V
C269 1-162-215-31 CERAMIC 47PF 5% 50V
C270 1-162-215-31 CERAMIC 47PF 5% 50V
< CONNECTOR >
CNE214 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D251 8-719-911-19 DIODE 1SS119-25
D252 8-719-911-19 DIODE 1SS119-25
< IC >
IC251 8-759-529-20 IC NJM2296D
IC252 8-759-529-20 IC NJM2296D
< JACK >
J251 1-537-943-11 TERMINAL, S (MONITOR S-VIDEO OUT)
J252 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO 1 S-VIDEO OUT/IN)
J253 1-537-943-11 TERMINAL, S (TV/LD S-VIDEO IN)
< RESISTOR >
R251 1-249-403-11 CARBON 68 5% 1/4W F
R252 1-249-429-11 CARBON 10K 5% 1/4W
R253 1-249-403-11 CARBON 68 5% 1/4W F
R254 1-249-403-11 CARBON 68 5% 1/4W F
R255 1-249-403-11 CARBON 68 5% 1/4W F
R256 1-249-429-11 CARBON 10K 5% 1/4W
R257 1-249-403-11 CARBON 68 5% 1/4W F
R258 1-249-403-11 CARBON 68 5% 1/4W F
R260 1-249-403-11 CARBON 68 5% 1/4W F
R261 1-249-403-11 CARBON 68 5% 1/4W F
**************************************************************
* A-4417-192-A SP BOARD, COMPLETE
******************
< CAPACITOR >
C624 1-126-964-11 ELECT 10uF 20% 50V
C626 1-136-153-00 FILM 0.01uF 5% 50V
C724 1-126-964-11 ELECT 10uF 20% 50V
C726 1-136-153-00 FILM 0.01uF 5% 50V
C794 1-126-968-11 ELECT 100uF 20% 50V
C795 1-126-951-11 ELECT 470uF 20% 35V
< CONNECTOR >
* CND602 1-564-337-00 PIN, CONNECTOR 3P
CNE604 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNJ701 1-774-136-11 CONNECTOR, ROUND TYPE 6P
(WIRELESS REAR SPEAKER)
CNS603 1-568-439-11 SOCKET, CONNECTOR 7P
CNV601 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
< DIODE >
D543 8-719-911-19 DIODE 1SS119-25
D605 8-719-911-19 DIODE 1SS119-25
D606 8-719-911-19 DIODE 1SS119-25
D607 8-719-911-19 DIODE 1SS119-25
D649 8-719-911-19 DIODE 1SS119-25
D705 8-719-911-19 DIODE 1SS119-25
D706 8-719-911-19 DIODE 1SS119-25
D749 8-719-911-19 DIODE 1SS119-25
< IC >
IC702 8-759-605-01 IC M5F78M18L
< JACK >
J501 1-770-157-21 JACK, PIN 2P (WOOFER AUDIO OUT)
< COIL >
L601 1-411-906-11 COIL, AIR-CORE
L701 1-411-906-11 COIL, AIR-CORE
L751 1-411-906-11 COIL, AIR-CORE
REAR AMP S VIDEO
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
To Next Page
