– 60 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SP SWITCH
< TRANSISTOR >
Q544 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q609 8-729-281-53 TRANSISTOR 2SC1815-GR
Q610 8-729-900-63 TRANSISTOR DTA124ES
Q611 8-729-900-63 TRANSISTOR DTA124ES
Q645 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q709 8-729-281-53 TRANSISTOR 2SC1815-GR
Q710 8-729-900-63 TRANSISTOR DTA124ES
Q745 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q747 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q748 8-729-030-19 TRANSISTOR 2SB1640
< RESISTOR >
R543 1-249-429-11 CARBON 10K 5% 1/4W
R544 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R545 1-249-393-11 CARBON 10 5% 1/4W F
R546 1-249-421-11 CARBON 2.2K 5% 1/4W F
R629 1-247-866-11 CARBON 30K 5% 1/4W
R630 1-249-386-11 CARBON 2.7 5% 1/6W F
R631 1-249-433-11 CARBON 22K 5% 1/4W
! R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R635 1-249-431-11 CARBON 15K 5% 1/4W
R636 1-249-433-11 CARBON 22K 5% 1/4W
R646 1-249-432-11 CARBON 18K 5% 1/4W
R647 1-249-429-11 CARBON 10K 5% 1/4W
R648 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R649 1-249-393-11 CARBON 10 5% 1/4W F
R729 1-247-866-11 CARBON 30K 5% 1/4W
R730 1-249-386-11 CARBON 2.7 5% 1/6W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
! R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
R737 1-249-429-11 CARBON 10K 5% 1/4W
R738 1-247-887-00 CARBON 220K 5% 1/4W
R743 1-249-425-11 CARBON 4.7K 5% 1/4W F
R744 1-249-425-11 CARBON 4.7K 5% 1/4W F
R745 1-249-421-11 CARBON 2.2K 5% 1/4W F
R746 1-249-421-11 CARBON 2.2K 5% 1/4W F
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R749 1-249-393-11 CARBON 10 5% 1/4W F
! R784 1-249-389-11 CARBON 4.7 5% 1/4W F
R787 1-249-429-11 CARBON 10K 5% 1/4W
R788 1-247-887-00 CARBON 220K 5% 1/4W
< RELAY >
RY503 1-515-793-11 RELAY
RY601 1-515-920-11 RELAY (24V)
RY701 1-515-920-11 RELAY (24V)
RY901 1-515-999-11 RELAY, POWER
< TRANSFORMER >
! T902 1-450-358-11 TRANSFORMER, POWER
**************************************************************
* 1-670-101-11 SP SWITCH BOARD
***************
< CONNECTOR >
CNS104 1-770-404-11 HOUSING, CONNECTOR (PC BOARD) 11P
< DIODE >
D122 8-719-911-19 DIODE 1SS119-25
D123 8-719-911-19 DIODE 1SS119-25
< RESISTOR >
RR141 1-249-413-11 CARBON 470 5% 1/4W F
RR151 1-249-415-11 CARBON 680 5% 1/4W F
RR152 1-249-417-11 CARBON 1K 5% 1/4W F
RR153 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S114 1-762-751-11 SWITCH, TACTILE (DISPLAY)
S125 1-762-751-11 SWITCH, TACTILE (SHIFT)
S126 1-762-751-11 SWITCH, TACTILE (FM/AM)
S127 1-762-751-11 SWITCH, TACTILE (PRESET TUNING -)
S128 1-762-751-11 SWITCH, TACTILE (PRESET TUNING +)
S151 1-762-751-11 SWITCH, TACTILE (1/u)
S155 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
**************************************************************
* 1-669-449-11 STANDBY BOARD
*************
< CONNECTOR >
* CNP905 1-580-230-21 PIN, CONNECTOR (PC BOARD) 2P
CNV901 1-564-321-00 PIN, CONNECTOR 2P
* CNV902 1-565-792-11 PIN, CONNECTOR 2P
< DIODE >
D907 8-719-911-19 DIODE 1SS119-25
< FUSE >
! F901 1-532-504-51 FUSE (T4AL/250V)
! F903 1-532-464-51 FUSE (T2.5AL/250V)
< FUSE HOLDER >
FH901 1-533-223-11 HOLDER, FUSE
FH902 1-533-223-11 HOLDER, FUSE
FH903 1-533-223-11 HOLDER, FUSE
FH951 1-533-223-11 HOLDER, FUSE
FH952 1-533-223-11 HOLDER, FUSE
FH953 1-533-223-11 HOLDER, FUSE
< SWITCH >
S501 1-692-196-11 SWITCH, SLIDE (IMPEDANCE SELECTOR)
< TERMINAL >
TM701 1-694-431-21 TERMINAL BOARD (SP)
(SPEAKERS REAR, CENTER)
**************************************************************
SP
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
STANDBY
