– 61 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SURR
* A-4407-589-A STANDBY (2) BOARD, COMPLETE
***************************
< CAPACITOR >
C901 1-136-157-00 FILM 0.022uF 5% 50V
C902 1-136-157-00 FILM 0.022uF 5% 50V
C903 1-126-768-11 ELECT 2200uF 20% 16V
C904 1-126-960-11 ELECT 1uF 20% 50V
C905 1-126-959-11 ELECT 0.47uF 20% 50V
C906 1-124-464-11 ELECT 0.22uF 20% 50V
C913 1-164-159-11 CERAMIC 0.1uF 50V
C914 1-164-159-11 CERAMIC 0.1uF 50V
C916 1-164-159-11 CERAMIC 0.1uF 50V
C917 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNE905 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CNE951 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D901 8-719-200-82 DIODE 11ES2
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-911-19 DIODE 1SS119-25
D906 8-719-911-19 DIODE 1SS119-25
< GROUND TERMINAL >
* EB900 1-537-738-21 TERMINAL, EARTH
< IC >
IC901 8-759-333-83 IC NJM2103D
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q902 8-729-026-68 TRANSISTOR 2SD2525(TP)
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-428-11 CARBON 8.2K 5% 1/4W F
R906 1-249-421-11 CARBON 2.2K 5% 1/4W F
R908 1-249-433-11 CARBON 22K 5% 1/4W
R909 1-249-439-11 CARBON 68K 5% 1/4W
R910 1-249-437-11 CARBON 47K 5% 1/4W
R912 1-249-430-11 CARBON 12K 5% 1/4W
**************************************************************
* A-4407-575-A SURR BOARD, COMPLETE
********************
< CAPACITOR >
C300 1-124-589-11 ELECT 47uF 20% 16V
C301 1-162-282-31 CERAMIC 100PF 10% 50V
C302 1-162-294-31 CERAMIC 0.001uF 10% 50V
C303 1-124-589-11 ELECT 47uF 20% 16V
C355 1-126-925-11 ELECT 470uF 20% 10V
C356 1-126-933-11 ELECT 100uF 20% 16V
C357 1-126-514-11 ELECT 22uF 20% 10V
C358 1-126-514-11 ELECT 22uF 20% 10V
C400 1-102-951-00 CERAMIC 15PF 5% 50V
C401 1-136-165-00 FILM 0.1uF 5% 50V
C402 1-102-852-91 CERAMIC 47PF 5% 50V
C403 1-130-469-00 MYLAR 680PF 5% 50V
C404 1-136-157-00 FILM 0.022uF 5% 50V
C405 1-102-973-00 CERAMIC 100PF 5% 50V
C406 1-102-953-00 CERAMIC 18PF 5% 50V
C407 1-136-161-00 FILM 0.047uF 5% 50V
C408 1-126-925-11 ELECT 470uF 20% 10V
C409 1-124-261-00 ELECT 10uF 20% 50V
C410 1-126-925-11 ELECT 470uF 20% 10V
C411 1-124-261-00 ELECT 10uF 20% 50V
C412 1-136-164-00 FILM 0.082uF 5% 50V
C413 1-124-465-00 ELECT 0.47uF 20% 50V
C414 1-124-261-00 ELECT 10uF 20% 50V
C415 1-130-477-00 MYLAR 0.0033uF 5% 50V
C416 1-136-177-00 FILM 1uF 5% 50V
C417 1-162-294-31 CERAMIC 0.001uF 10% 50V
C418 1-124-261-00 ELECT 10uF 20% 50V
C419 1-136-164-00 FILM 0.082uF 5% 50V
C420 1-126-925-11 ELECT 470uF 20% 10V
C421 1-136-177-00 FILM 1uF 5% 50V
C422 1-124-465-00 ELECT 0.47uF 20% 50V
C423 1-126-301-11 ELECT 1uF 20% 50V
C424 1-126-925-11 ELECT 470uF 20% 10V
C425 1-126-301-11 ELECT 1uF 20% 50V
C426 1-124-252-00 ELECT 0.33uF 20% 50V
C427 1-136-177-00 FILM 1uF 5% 50V
C428 1-136-177-00 FILM 1uF 5% 50V
C429 1-128-551-11 ELECT 22uF 20% 35V
C430 1-162-282-31 CERAMIC 100PF 10% 50V
C431 1-164-159-11 CERAMIC 0.1uF 50V
C432 1-124-261-00 ELECT 10uF 20% 50V
C433 1-164-159-11 CERAMIC 0.1uF 50V
C434 1-136-165-00 FILM 0.1uF 5% 50V
C435 1-136-165-00 FILM 0.1uF 5% 50V
C436 1-124-261-00 ELECT 10uF 20% 50V
C437 1-164-159-11 CERAMIC 0.1uF 50V
C438 1-124-261-00 ELECT 10uF 20% 50V
C440 1-136-165-00 FILM 0.1uF 5% 50V
C441 1-136-165-00 FILM 0.1uF 5% 50V
C442 1-124-261-00 ELECT 10uF 20% 50V
C444 1-124-465-00 ELECT 0.47uF 20% 50V
C445 1-124-465-00 ELECT 0.47uF 20% 50V
C446 1-126-163-11 ELECT 4.7uF 20% 50V
C447 1-126-163-11 ELECT 4.7uF 20% 50V
C448 1-124-465-00 ELECT 0.47uF 20% 50V
C449 1-124-465-00 ELECT 0.47uF 20% 50V
C450 1-126-163-11 ELECT 4.7uF 20% 50V
C451 1-126-163-11 ELECT 4.7uF 20% 50V
C452 1-124-250-11 ELECT 0.15uF 20% 50V
C453 1-124-250-11 ELECT 0.15uF 20% 50V
C454 1-126-162-11 ELECT 3.3uF 20% 50V
STANDBY (2)
To Next Page
