– 62 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C455 1-126-162-11 ELECT 3.3uF 20% 50V
C456 1-124-250-11 ELECT 0.15uF 20% 50V
C457 1-124-250-11 ELECT 0.15uF 20% 50V
C458 1-124-261-00 ELECT 10uF 20% 50V
C476 1-102-518-11 CERAMIC 33PF 5% 50V
C495 1-136-165-00 FILM 0.1uF 5% 50V
CC09 1-162-282-31 CERAMIC 100PF 10% 50V
CC10 1-162-282-31 CERAMIC 100PF 10% 50V
CC11 1-162-282-31 CERAMIC 100PF 10% 50V
CC12 1-162-282-31 CERAMIC 100PF 10% 50V
CC13 1-162-282-31 CERAMIC 100PF 10% 50V
CC59 1-162-282-31 CERAMIC 100PF 10% 50V
CC60 1-162-282-31 CERAMIC 100PF 10% 50V
CC61 1-162-282-31 CERAMIC 100PF 10% 50V
CC62 1-162-282-31 CERAMIC 100PF 10% 50V
CC63 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
* CNP702 1-564-519-11 PLUG, CONNECTOR 4P
CNS211 1-568-439-11 SOCKET, CONNECTOR 7P
CNS401 1-569-060-11 SOCKET, CONNECTOR 11P
CNS402 1-568-442-11 SOCKET, CONNECTOR 9P
CNS406 1-569-060-11 SOCKET, CONNECTOR 11P
< DIODE >
D401 8-719-070-77 DIODE SVC201SPA-M1-AC
< IC >
IC300 8-759-805-14 IC LC7822
IC400 8-759-528-36 IC CXA8081S
IC401 8-759-528-35 IC CXA8079S
IC403 8-759-805-15 IC LC7823
IC404 8-759-634-51 IC M5218AP
IC407 8-759-604-38 IC M5F78M10L
< JACK >
J300 1-774-411-11 JACK, PIN 6P
(TV/LD AUDIO IN, VIDEO 2 AUDIO OUT/IN)
J301 1-573-028-31 JACK, PIN 4P (VIDEO 1 AUDIO OUT/IN)
< COIL >
L400 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R301 1-249-417-11 CARBON 1K 5% 1/4W F
R304 1-249-441-11 CARBON 100K 5% 1/4W
R305 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-249-417-11 CARBON 1K 5% 1/4W F
R310 1-249-417-11 CARBON 1K 5% 1/4W F
R312 1-249-441-11 CARBON 100K 5% 1/4W
R314 1-249-441-11 CARBON 100K 5% 1/4W
R315 1-249-417-11 CARBON 1K 5% 1/4W F
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-249-425-11 CARBON 4.7K 5% 1/4W F
R321 1-249-397-11 CARBON 22 5% 1/4W F
R322 1-249-417-11 CARBON 1K 5% 1/4W F
R323 1-249-397-11 CARBON 22 5% 1/4W F
R400 1-249-441-11 CARBON 100K 5% 1/4W
R401 1-249-436-11 CARBON 39K 5% 1/4W
R402 1-249-425-11 CARBON 4.7K 5% 1/4W F
R403 1-249-417-11 CARBON 1K 5% 1/4W F
R451 1-249-435-11 CARBON 33K 5% 1/4W
R458 1-249-436-11 CARBON 39K 5% 1/4W
**************************************************************
* 1-670-095-11 SW BOARD
*********
< CONNECTOR >
* CNS107 1-695-808-11 CONNECTOR, PC BOARD 8P
< DIODE >
D113 8-719-058-64 DIODE SEL5823A-TP15 (SURROUND)
D114 8-719-058-64 DIODE SEL5823A-TP15 (BASS/TREBLE)
D115 8-719-058-64 DIODE SEL5823A-TP15 (INDEX)
< RESISTOR >
R149 1-249-411-11 CARBON 330 5% 1/4W
RR131 1-249-409-11 CARBON 220 5% 1/4W F
RR132 1-249-411-11 CARBON 330 5% 1/4W
RR133 1-249-413-11 CARBON 470 5% 1/4W F
RR134 1-249-415-11 CARBON 680 5% 1/4W F
RR135 1-249-417-11 CARBON 1K 5% 1/4W F
RR136 1-249-419-11 CARBON 1.5K 5% 1/4W F
RR137 1-249-421-11 CARBON 2.2K 5% 1/4W F
RR138 1-249-425-11 CARBON 4.7K 5% 1/4W F
RR139 1-249-429-11 CARBON 10K 5% 1/4W
RR142 1-249-409-11 CARBON 220 5% 1/4W F
RR143 1-249-411-11 CARBON 330 5% 1/4W
RR144 1-249-413-11 CARBON 470 5% 1/4W F
RR145 1-249-415-11 CARBON 680 5% 1/4W F
RR146 1-249-417-11 CARBON 1K 5% 1/4W F
RR147 1-249-419-11 CARBON 1.5K 5% 1/4W F
RR148 1-249-421-11 CARBON 2.2K 5% 1/4W F
< SWITCH >
S102 1-762-751-11 SWITCH, TACTILE (FM MODE)
S103 1-762-751-11 SWITCH, TACTILE (TUNING -)
S104 1-762-751-11 SWITCH, TACTILE (TUNING +)
S105 1-762-751-11 SWITCH, TACTILE (MEMORY)
S106 1-762-751-11 SWITCH, TACTILE (CURSOR MODE)
S107 1-762-751-11 SWITCH, TACTILE (SET UP)
S108 1-762-751-11 SWITCH, TACTILE (∧)
S109 1-762-751-11 SWITCH, TACTILE (<)
S110 1-762-751-11 SWITCH, TACTILE (∨)
S111 1-762-751-11 SWITCH, TACTILE (>)
S115 1-762-751-11 SWITCH, TACTILE (RDS PTY)
S116 1-762-751-11 SWITCH, TACTILE (RDS EON)
S117 1-762-751-11 SWITCH, TACTILE (5.1/DVD INPUT)
S118 1-762-751-11 SWITCH, TACTILE (TONE ON/OFF)
S119 1-762-751-11 SWITCH, TACTILE (BASS BOOST)
S120 1-762-751-11 SWITCH, TACTILE (SOUND FIELD GENRE)
S121 1-762-751-11 SWITCH, TACTILE (SOUND FIELD MODE)
SURR SW
