Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
VIDEO (3)
* 1-670-100-11 VIDEO (3) BOARD
***************
< CAPACITOR >
C299 1-164-159-11 CERAMIC 0.1uF 50V
CC14 1-162-282-31 CERAMIC 100PF 10% 50V
CC64 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN307 1-564-524-11 PLUG, CONNECTOR 9P
< GROUND TERMINAL >
EB100 1-537-738-21 TERMINAL, EARTH
< JACK >
J298 1-784-808-11 TERMINAL, S (VIDEO 3 INPUT S-VIDEO)
J299 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P
(VIDEO 3 INPUT VIDEO/AUDIO)
< RESISTOR >
R297 1-249-403-11 CARBON 68 5% 1/4W F
R298 1-249-403-11 CARBON 68 5% 1/4W F
R299 1-249-403-11 CARBON 68 5% 1/4W F
R321 1-249-417-11 CARBON 1K 5% 1/4W F
R371 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* 1-670-098-11 VOLUME BOARD
*************
< CONNECTOR >
CNP101 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNP106 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNS402 1-569-323-11 SOCKET, CONNECTOR 19P
< RESISTOR >
R199 1-249-411-11 CARBON 330 5% 1/4W
< VARIABLE RESISTOR >
RV401 1-225-445-11 RES, VAR, CARBON 100KX6 (MASTER VOLUME)
**************************************************************
MISCELLANEOUS
**************
3 1-769-877-11 WIRE (FLAT TYPE)(7 CORE)(90mm)
6 1-769-875-11 WIRE (FLAT TYPE)(7 CORE)(70mm)
8 1-693-409-11 TUNER
10 1-769-941-11 WIRE (FLAT TYPE)(11 CORE)
11 1-769-908-11 WIRE (FLAT TYPE)(9 CORE)
! 14 1-769-744-11 CORD, POWER
71 1-783-777-11 WIRE (FLAT TYPE)(13 CORE)
72 1-773-024-11 WIRE (FLAT TYPE)(15 CORE)(320mm)
106 1-773-110-11 WIRE (FLAT TYPE)(19 CORE)
109 1-773-008-11 WIRE (FLAT TYPE)(15 CORE)(140mm)
! CNJ909 1-526-794-11 OUTLET, AC (AC OUTLET)
FL101 1-517-770-11 INDICATOR TUBE, FLUORESCENT
VOLUME
S122 1-762-751-11 SWITCH, TACTILE (SOUND FIELD ON/OFF)
**************************************************************
* 1-670-097-11 VIDEO BOARD
***********
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-162-215-31 CERAMIC 47PF 5% 50V
C206 1-162-215-31 CERAMIC 47PF 5% 50V
C207 1-162-215-31 CERAMIC 47PF 5% 50V
C208 1-126-960-11 ELECT 1uF 20% 50V
C209 1-164-159-11 CERAMIC 0.1uF 50V
C210 1-164-159-11 CERAMIC 0.1uF 50V
C211 1-164-159-11 CERAMIC 0.1uF 50V
C212 1-164-159-11 CERAMIC 0.1uF 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CNE217 1-564-505-11 PLUG, CONNECTOR 2P
CNS211 1-569-321-11 SOCKET, CONNECTOR 15P
CNS212 1-568-439-11 SOCKET, CONNECTOR 7P
< DIODE >
D201 8-719-911-19 DIODE 1SS119-25
D202 8-719-911-19 DIODE 1SS119-25
< IC >
IC201 8-759-529-20 IC NJM2296D
IC202 8-759-701-65 IC NJM79M05FA
< JACK >
J201 1-770-337-11 JACK, PIN 3P
(VIDEO 1 VIDEO OUT/IN, MONITOR VIDEO OUT)
J202 1-695-317-21 JACK, PIN 2P (VIDEO 2 VIDEO OUT/IN)
J203 1-695-317-21 JACK, PIN 2P
(5.1/DVD INPUT, TV/LD VIDEO IN)
J204 1-563-330-11 JACK (S-LINK CTRL A1)
< RESISTOR >
R201 1-249-403-11 CARBON 68 5% 1/4W F
R202 1-249-403-11 CARBON 68 5% 1/4W F
R203 1-249-403-11 CARBON 68 5% 1/4W F
R204 1-249-403-11 CARBON 68 5% 1/4W F
R205 1-249-403-11 CARBON 68 5% 1/4W F
R206 1-249-403-11 CARBON 68 5% 1/4W F
R207 1-249-403-11 CARBON 68 5% 1/4W F
**************************************************************
VIDEOSW
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
