– 64 –
Ref. No. Part No. Description Remark
Sony Corporation
Home A&V Products Company
9-922-909-11
98G097548-1
Printed in Hungary © 1998. 7
Published by Quality Assurance Dept.
(Shibaura)
STR-DB725/DB825
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
Q505 8-729-209-15 TRANSISTOR 2SD2012
Q506 8-749-010-25 IC MN2488-OPY-M
Q507 8-749-010-26 IC MP1620-OPY-M
Q555 8-729-209-15 TRANSISTOR 2SD2012
Q556 8-749-010-25 IC MN2488-OPY-M
Q557 8-749-010-26 IC MP1620-OPY-M
Q605 8-729-209-15 TRANSISTOR 2SD2012
Q606 8-749-010-25 IC MN2488-OPY-M
Q607 8-749-010-26 IC MP1620-OPY-M
Q705 8-729-209-15 TRANSISTOR 2SD2012
Q706 8-749-010-25 IC MN2488-OPY-M
Q707 8-749-010-26 IC MP1620-OPY-M
Q755 8-729-209-15 TRANSISTOR 2SD2012
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
! T901 1-431-811-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-726-11 REMOTE COMMANDER (RM-LJ301)(DB825)
1-501-374-11 ANTENNA, LOOP
3-810-765-21 MANUAL,COMMONNESS INSTRUCTION
(FOR CONTROL A1)
(ENGLISH,FRENCH,GERMAN,SPANISH,DUTCH,
SWEDISH,ITALIAN,PORTUGUESE,CHINESE)(DB825)
3-864-029-61 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,DUTCH,SWEDISH)
3-864-029-71 MANUAL, INSTRUCTION
(GERMAN,SPANISH,ITALIAN,PORTUGUESE)
3-864-230-11 MANUAL, INSTRUCTION (RM-PP401)
(ENGLISH)(DB725)
3-864-230-21 MANUAL, INSTRUCTION (RM-PP401)
(FRENCH,SPANISH)(DB725)
3-864-230-31 MANUAL, INSTRUCTION (RM-PP401)
(DUTCH,SWEDISH,GERMAN,ITALIAN,PORTUGUESE)(DB725)
3-864-441-11 MANUAL, INSTRUCTION (RM-LJ301)
(ENGLISH)(DB825)
3-864-441-21 MANUAL, INSTRUCTION (RM-LJ301)
(FRENCH,SPANISH)(DB825)
3-864-441-41 MANUAL, INSTRUCTION (RM-LJ301)
(DUTCH,SWEDISH,GERMAN,ITALIAN,PORTUGUESE)
(DB825)
4-212-261-01 COVER (FRONT)(FOR RM-LJ301)(DB825)
4-210-990-01 LID (RM-LJ301), BATTERY CASE (DB825)
4-978-977-01 LID (RM-PP401), BATTERY CASE
8-917-634-90 REMOTE COMMADER RM-PP401 (DB725)
X-4950-287-1 LID ASSY (FRONT)(FOR RM-PP401)(DB725)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-885-09 SCREW +BVTT 4X16 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#3 7-685-132-19 SCREW +BTP 2.6X5 TYPE2 N-S
