NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
CND : Canadian model
AUS : Australian model
MY : Malaysia model
SP : Singapore model
CH : Chinese model
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 66 —
SECTION 6
ELECTRICAL PARTS LIST
* 1-673-359-11 4/8 BOARD
********
< CONNECTOR >
CNP809 1-785-102-11 PIN, CONNECTOR 4P
* CNP805 1-564-216-00 PIN, CONNECTOR 5P
< DIODE >
D804 8-719-053-18 DIODE 1SR154-400TE-25
D805 8-719-053-18 DIODE 1SR154-400TE-25
< SWITCH >
S801 1-571-309-11 SWITCH (INPEDANCE SELECTOR)
*********************************************************
* 1-673-353-11 AC BOARD
********
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C901 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C902 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C905 1-126-767-11 ELECT 1000uF 20% 16V
< JACK >
! CNJ901 1-251-718-11 OUTLET (2 GANG), AC
(US,CND,CH)(AC OUTLET)
! CNJ901 1-785-285-11 OUTLET, AC (1P)(AEP,MY,SP)(AC OUTLET)
! CNJ901 1-251-417-11 OUTLET, AC (AUS)(AC OUTLET)
< CONNECTOR >
CNP809 1-784-921-11 PIN, CONNECTOR 4P
< CONNECTOR >
CNV901 1-564-321-00 PIN, CONNECTOR 2P
* CNV902 1-565-792-11 PIN, CONNECTOR 2P
< DIODE >
D901 8-719-053-18 DIODE 1SR154-400TE-25
D902 8-719-053-18 DIODE 1SR154-400TE-25
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 8-719-053-18 DIODE 1SR154-400TE-25
D905 8-719-801-78 DIODE 1SS184-TE85L
D907 8-719-016-74 DIODE 1SS352-TPH3
< EARTH >
* EB901 1-537-738-21 TERMINAL, EARTH (US,CND)
< FUSE >
! F901 1-533-311-11 FUSE, GLASS CYLINDRICAL(DIA.5) 8A/125V
(US,CND)
! F901 1-532-504-51 FUSE TIME LAG 4A/250V (EXCEPT US,CND)
! F903 1-532-464-51 FUSE TIME LAG 2.5A/250V (EXCEPT US,CND)
< TRANSISTOR >
Q901 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
< RESISTOR >
R902 1-216-073-00 METAL CHIP 10K 5% 1/10W
R903 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
< RELAY >
RY901 1-755-298-11 RELAY
< TRANSFORMER >
! T902 1-433-685-11 TRANSFORMER, POWER (AEP,MY,SP,AUS,CH)
! T902 1-433-686-11 TRANSFORMER, POWER (US,CND)
************************************************************
* 1-673-354-11 DC BOARD
********
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C801 1-104-664-11 ELECT 47uF 20% 25V
C803 1-125-900-12 ELECT 15000uF 20% 71V
(DB930/V929X)
C803 1-125-895-11 ELECT 12000uF 20% 71V
(DB830)
C804 1-125-900-12 ELECT 15000uF 20% 71V
(DB930/V929X)
C804 1-125-895-11 ELECT 12000uF 20% 71V
(DB830)
C805 1-130-781-00 FILM 0.22uF 10% 100V
C806 1-130-781-00 FILM 0.22uF 10% 100V
C807 1-128-555-91 ELECT 470uF 20% 63V
C808 1-126-967-11 ELECT 47uF 20% 50V
C809 1-126-967-11 ELECT 47uF 20% 50V
