Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 73 —
JR133 1-216-296-91 SHORT 0
JR134 1-216-296-91 SHORT 0
JR135 1-216-296-91 SHORT 0
JR136 1-216-296-91 SHORT 0
JR137 1-216-296-91 SHORT 0
JR138 1-216-296-91 SHORT 0
JR139 1-216-296-91 SHORT 0
JR140 1-216-296-91 SHORT 0
JR141 1-216-296-91 SHORT 0
JR142 1-216-296-91 SHORT 0
JR143 1-216-296-91 SHORT 0
JR144 1-216-296-91 SHORT 0
JR145 1-216-296-91 SHORT 0
JR146 1-216-296-91 SHORT 0
JR147 1-216-296-91 SHORT 0
JR148 1-216-296-91 SHORT 0
JR149 1-216-296-91 SHORT 0
JR150 1-216-296-91 SHORT 0
JR151 1-216-296-91 SHORT 0
JR152 1-216-296-91 SHORT 0
JR153 1-216-296-91 SHORT 0
JR154 1-216-296-91 SHORT 0
JR155 1-216-296-91 SHORT 0
JR156 1-216-296-91 SHORT 0
JR157 1-216-296-91 SHORT 0
JR158 1-216-296-91 SHORT 0
JR159 1-216-296-91 SHORT 0
JR162 1-216-296-91 SHORT 0
JR168 1-216-295-91 SHORT 0
< JUMPER RESISTOR >
JW101 1-216-295-91 SHORT 0
JW102 1-216-295-91 SHORT 0
JW103 1-216-295-91 SHORT 0
JW104 1-216-295-91 SHORT 0
JW105 1-216-295-91 SHORT 0
JW106 1-216-295-91 SHORT 0
< TRANSISTOR >
Q101 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q102 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q103 8-729-027-43 TRANSISTOR RT1N141C-TP-1
Q104 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q105 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
(DB930/V929X)
Q129 8-729-801-93 TRANSISTOR 2SD1387-34-TP (DB930/V929X)
Q130 8-729-801-93 TRANSISTOR 2SD1387-34-TP (DB930/V929X)
< RESISTOR >
R101 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DB930/V929X)
R103 1-216-089-91 RES,CHIP 47K 5% 1/10W
R104 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DB930:AEP)
R104 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R105 1-216-001-00 METAL CHIP 10 5% 1/10W
R106 1-216-001-00 METAL CHIP 10 5% 1/10W
(DB930/V929X)
R107 1-216-001-00 METAL CHIP 10 5% 1/10W
(DB930/V929X)
R108 1-216-097-91 RES,CHIP 100K 5% 1/10W
R109 1-216-097-91 RES,CHIP 100K 5% 1/10W
R110 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
R113 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DB930/V929X)
R114 1-216-134-00 METAL CHIP 2.2 5% 1/8W
(DB930:AEP,MY,SP,AUS/V929X
R114 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DB930:US,CND,MY,SP,AUS/V929X)
R115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-073-00 METAL CHIP 10K 5% 1/10W
R117 1-216-081-00 METAL CHIP 22K 5% 1/10W
R118 1-216-081-00 METAL CHIP 22K 5% 1/10W
R119 1-216-049-91 RES,CHIP 1K 5% 1/10W
R120 1-216-049-91 RES,CHIP 1K 5% 1/10W
R121 1-216-049-91 RES,CHIP 1K 5% 1/10W
R122 1-216-073-00 METAL CHIP 10K 5% 1/10W
R123 1-216-049-91 RES,CHIP 1K 5% 1/10W
R124 1-216-033-00 METAL CHIP 220 5% 1/10W
R125 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
(DB930/V929X)
R126 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DB930/V929X)
R127 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R128 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R129 1-216-049-91 RES,CHIP 1K 5% 1/10W
R130 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R131 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R132 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R133 1-216-033-00 METAL CHIP 220 5% 1/10W
R134 1-216-089-91 RES,CHIP 47K 5% 1/10W
R135 1-216-037-00 METAL CHIP 330 5% 1/10W
R136 1-216-089-91 RES,CHIP 47K 5% 1/10W
R137 1-216-089-91 RES,CHIP 47K 5% 1/10W
R138 1-216-001-00 METAL CHIP 10 5% 1/10W
R139 1-216-089-91 RES,CHIP 47K 5% 1/10W
R140 1-216-037-00 METAL CHIP 330 5% 1/10W
R141 1-216-041-00 METAL CHIP 470 5% 1/10W
R142 1-216-045-00 METAL CHIP 680 5% 1/10W
R143 1-216-049-91 RES,CHIP 1K 5% 1/10W
R144 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R145 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R146 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R147 1-216-049-91 RES,CHIP 1K 5% 1/10W
R148 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R149 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R150 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R151 1-216-041-00 METAL CHIP 470 5% 1/10W
R152 1-216-045-00 METAL CHIP 680 5% 1/10W
R153 1-216-037-00 METAL CHIP 330 5% 1/10W
R154 1-216-041-00 METAL CHIP 470 5% 1/10W
R158 1-216-045-00 METAL CHIP 680 5% 1/10W
R161 1-216-049-91 RES,CHIP 1K 5% 1/10W
R162 1-216-049-91 RES,CHIP 1K 5% 1/10W
R163 1-216-073-00 METAL CHIP 10K 5% 1/10W
R164 1-216-097-91 RES,CHIP 100K 5% 1/10W
