– 43 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S243 1-762-196-21 SWITCH, TACT (SOUND FIELD ON/OFF)
S244 1-762-196-21 SWITCH, TACT (SOUND FIELD – MODE)
************************************************************
A-4419-015-A MAIN BOARD, COMPLETE
*********************
3-905-609-01 SCREW (TRANSISTOR)
4-812-134-00 RIVET (DIA. 3.5), NYLON
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C3 1-162-288-31 CERAMIC 330PF 10% 50V
C4 1-126-961-11 ELECT 2.2uF 20% 50V
C5 1-164-159-11 CERAMIC 0.1uF 50V
C6 1-162-291-31 CERAMIC 560PF 10% 50V
C7 1-102-527-11 CERAMIC 82PF 5% 50V
C8 1-102-852-91 CERAMIC 47PF 5% 50V
C9 1-126-795-11 ELECT 10uF 20% 50V
C302 1-126-959-11 ELECT 0.47uF 20% 50V
C303 1-130-494-11 MYLAR 0.082uF 5% 50V
C304 1-137-367-11 FILM 0.0033uF 5% 50V
C305 1-130-494-11 MYLAR 0.082uF 5% 50V
C307 1-126-795-11 ELECT 10uF 20% 50V
C308 1-126-795-11 ELECT 10uF 20% 50V
C309 1-137-358-11 FILM 100PF 5% 50V
C310 1-126-795-11 ELECT 10uF 20% 50V
C312 1-126-934-11 ELECT 220uF 20% 10V
C313 1-124-252-00 ELECT 0.33uF 20% 50V
C314 1-136-165-00 FILM 0.1uF 5% 50V
C315 1-164-159-11 CERAMIC 0.1uF 50V
C316 1-126-961-11 ELECT 2.2uF 20% 50V
C319 1-102-951-00 CERAMIC 15PF 5% 50V
C320 1-102-852-91 CERAMIC 47PF 5% 50V
C322 1-126-795-11 ELECT 10uF 20% 50V
C323 1-126-925-11 ELECT 470uF 20% 10V
C324 1-126-934-11 ELECT 220uF 20% 10V
C325 1-136-165-00 FILM 0.1uF 5% 50V
C326 1-136-165-00 FILM 0.1uF 5% 50V
C327 1-126-959-11 ELECT 0.47uF 20% 50V
C328 1-126-963-11 ELECT 4.7uF 20% 50V
C329 1-126-959-11 ELECT 0.47uF 20% 50V
C330 1-126-963-11 ELECT 4.7uF 20% 50V
C331 1-124-250-11 ELECT 0.15uF 20% 50V
C332 1-126-962-11 ELECT 3.3uF 20% 50V
C333 1-124-250-11 ELECT 0.15uF 20% 50V
C334 1-137-372-11 FILM 0.022uF 5% 50V
C335 1-136-161-00 FILM 0.047uF 5% 50V
C336 1-126-959-11 ELECT 0.47uF 20% 50V
C337 1-126-795-11 ELECT 10uF 20% 50V
C338 1-126-795-11 ELECT 10uF 20% 50V
C339 1-126-795-11 ELECT 10uF 20% 50V
C340 1-126-795-11 ELECT 10uF 20% 50V
C341 1-126-925-11 ELECT 470uF 20% 10V
C342 1-126-962-11 ELECT 3.3uF 20% 50V
C343 1-126-962-11 ELECT 3.3uF 20% 50V
C344 1-136-165-00 FILM 0.1uF 5% 50V
C345 1-136-165-00 FILM 0.1uF 5% 50V
C346 1-126-959-11 ELECT 0.47uF 20% 50V
C347 1-126-963-11 ELECT 4.7uF 20% 50V
C348 1-126-959-11 ELECT 0.47uF 20% 50V
C349 1-126-963-11 ELECT 4.7uF 20% 50V
C350 1-124-250-11 ELECT 0.15uF 20% 50V
C351 1-126-962-11 ELECT 3.3uF 20% 50V
C352 1-136-165-00 FILM 0.1uF 5% 50V
C353 1-137-358-11 FILM 100PF 5% 50V
C357 1-164-159-11 CERAMIC 0.1uF 50V
C358 1-126-963-11 ELECT 4.7uF 20% 50V
C359 1-126-963-11 ELECT 4.7uF 20% 50V
C361 1-164-159-11 CERAMIC 0.1F 50V
C362 1-164-159-11 CERAMIC 0.1F 50V
C363 1-164-159-11 CERAMIC 0.1F 50V
C365 1-164-159-11 CERAMIC 0.1F 50V
C367 1-137-358-11 FILM 100PF 5% 50V
C368 1-126-934-11 ELECT 220uF 20% 10V
C369 1-136-177-00 FILM 1uF 5% 50V
C370 1-136-357-11 FILM 680PF 5% 100V
C371 1-124-250-11 ELECT 0.15uF 20% 50V
C372 1-137-358-11 FILM 100PF 5% 50V
C376 1-136-177-00 FILM 1uF 5% 50V
C377 1-136-177-00 FILM 1uF 5% 50V
C378 1-102-518-11 CERAMIC 33PF 5% 50V
C379 1-136-165-00 FILM 0.1uF 5% 50V
C380 1-136-177-00 FILM 1uF 5% 50V
C381 1-136-165-00 FILM 0.1uF 5% 50V
C382 1-102-953-00 CERAMIC 18PF 5% 50V
C406 1-164-159-11 CERAMIC 0.1uF 50V
C412 1-162-291-31 CERAMIC 560PF 10% 50V
C413 1-164-159-11 CERAMIC 0.1uF 50V
C415 1-164-159-11 CERAMIC 0.1uF 50V
C416 1-164-159-11 CERAMIC 0.1uF 50V
C427 1-124-252-00 ELECT 0.33uF 20% 50V
C428 1-130-489-00 MYLAR 0.033uF 5% 50V
C429 1-102-973-00 CERAMIC 100PF 5% 50V
C434 1-162-286-31 CERAMIC 220PF 10% 50V
C435 1-162-286-31 CERAMIC 220PF 10% 50V
C447 1-164-159-11 CERAMIC 0.1uF 50V
C477 1-124-252-00 ELECT 0.33uF 20% 50V
C478 1-130-489-00 MYLAR 0.033uF 5% 50V
C479 1-102-973-00 CERAMIC 100PF 5% 50V
C492 1-124-464-11 ELECT 0.22uF 20% 50V
C602 1-162-282-31 CERAMIC 100PF 10% 50V
C603 1-104-665-11 ELECT 100uF 20% 10V
C605 1-102-233-00 CERAMIC 33PF 10% 500V
C610 1-104-664-11 ELECT 47uF 20% 16V
C611 1-137-372-11 FILM 0.022uF 5% 50V
C620 1-162-286-31 CERAMIC 220PF 10% 50V
C652 1-162-282-31 CERAMIC 100PF 10% 50V
C653 1-104-665-11 ELECT 100uF 20% 10V
C655 1-102-233-00 CERAMIC 33PF 10% 500V
C660 1-104-664-11 ELECT 47uF 20% 16V
C661 1-137-372-11 FILM 0.022uF 5% 50V
C670 1-162-286-31 CERAMIC 220PF 10% 50V
C702 1-162-282-31 CERAMIC 100PF 10% 50V
C703 1-104-665-11 ELECT 100uF 20% 10V
C704 1-104-664-11 ELECT 47uF 20% 16V
KEY MAIN
To Next Page
