Sony STR-DE235 - Display Key

– 42 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X201 1-577-101-11 VIBRATOR, CERAMIC (4.19MHz)
************************************************************
A-4419-013-A KEY BOARD, COMPLETE
********************
< CONNECTOR >
CNS205 1-770-399-11 HOUSING, CONNECTOR (PC BOARD) 6P
CNS206 1-770-397-11 HOUSING, CONNECTOR (PC BOARD) 4P
CNS207 1-770-397-11 HOUSING, CONNECTOR (PC BOARD) 4P
< DIODE >
D228 8-719-046-39 LED SEL5821A-TH15 (BASS BOOST)
D233 8-719-046-39 LED SEL5821A-TH15 (CENTER)
D234 8-719-046-39 LED SEL5821A-TH15 (SET UP)
D235 8-719-046-39 LED SEL5821A-TH15 (NAME)
D236 8-719-046-39 LED SEL5821A-TH15 (EFFECT/DELAY)
D237 8-719-046-39 LED SEL5821A-TH15 (REAR)
D240 8-719-046-39 LED SEL5821A-TH15 (MUTING)
D241 8-719-911-19 DIODE 1SS119
< TRANSISTOR >
Q233 8-729-900-36 TRANSISTOR DTC124ES
Q234 8-729-900-36 TRANSISTOR DTC124ES
Q235 8-729-900-36 TRANSISTOR DTC124ES
Q236 8-729-900-36 TRANSISTOR DTC124ES
Q237 8-729-900-63 TRANSISTOR DTA124ES
Q239 8-729-900-36 TRANSISTOR DTC124ES
Q241 8-729-900-63 TRANSISTOR DTA124ES
Q242 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R228 1-249-406-11 CARBON 120 5% 1/4W
R233 1-249-406-11 CARBON 120 5% 1/4W
R234 1-249-406-11 CARBON 120 5% 1/4W
R235 1-249-406-11 CARBON 120 5% 1/4W
R236 1-249-406-11 CARBON 120 5% 1/4W
R237 1-249-406-11 CARBON 120 5% 1/4W
R240 1-249-406-11 CARBON 120 5% 1/4W
R248 1-249-411-11 CARBON 330 5% 1/4W
R249 1-249-413-11 CARBON 470 5% 1/4W
R250 1-249-415-11 CARBON 680 5% 1/4W
R251 1-249-417-11 CARBON 1K 5% 1/4W
R252 1-249-419-11 CARBON 1.5K 5% 1/4W
R253 1-249-421-11 CARBON 2.2K 5% 1/4W
R254 1-247-843-11 CARBON 3.3K 5% 1/4W
R255 1-249-425-11 CARBON 4.7K 5% 1/4W
R256 1-249-429-11 CARBON 10K 5% 1/4W
R257 1-249-411-11 CARBON 330 5% 1/4W
R258 1-249-413-11 CARBON 470 5% 1/4W
R259 1-249-415-11 CARBON 680 5% 1/4W
R260 1-249-417-11 CARBON 1K 5% 1/4W
R261 1-249-419-11 CARBON 1.5K 5% 1/4W
R262 1-249-421-11 CARBON 2.2K 5% 1/4W
R263 1-247-843-11 CARBON 3.3K 5% 1/4W
R264 1-249-425-11 CARBON 4.7K 5% 1/4W
R265 1-249-429-11 CARBON 10K 5% 1/4W
R266 1-249-411-11 CARBON 330 5% 1/4W
R267 1-249-413-11 CARBON 470 5% 1/4W
R268 1-249-415-11 CARBON 680 5% 1/4W
R269 1-249-417-11 CARBON 1K 5% 1/4W
R270 1-249-419-11 CARBON 1.5K 5% 1/4W
R271 1-249-421-11 CARBON 2.2K 5% 1/4W
R272 1-247-843-11 CARBON 3.3K 5% 1/4W
R273 1-249-425-11 CARBON 4.7K 5% 1/4W
R277 1-249-411-11 CARBON 330 5% 1/4W
R278 1-249-413-11 CARBON 470 5% 1/4W
R279 1-249-415-11 CARBON 680 5% 1/4W
R280 1-249-417-11 CARBON 1K 5% 1/4W
R281 1-249-419-11 CARBON 1.5K 5% 1/4W
R282 1-249-421-11 CARBON 2.2K 5% 1/4W
R283 1-247-843-11 CARBON 3.3K 5% 1/4W
R284 1-249-425-11 CARBON 4.7K 5% 1/4W
R285 1-249-429-11 CARBON 10K 5% 1/4W
R286 1-249-433-11 CARBON 22K 5% 1/4W
< SWITCH >
S202 1-762-196-21 SWITCH, TACT (RDS EON)
S203 1-762-196-21 SWITCH, TACT (3)
S204 1-762-196-21 SWITCH, TACT (2)
S205 1-762-196-21 SWITCH, TACT (1)
S206 1-762-196-21 SWITCH, TACT (TUNING –)
S207 1-762-196-21 SWITCH, TACT (TUNING +)
S208 1-762-196-21 SWITCH, TACT (PRESET/PTY SELECT –)
S209 1-762-196-21 SWITCH, TACT (PRESET/PTY SELECT +)
S210 1-762-196-21 SWITCH, TACT (DIRECT)
S211 1-762-196-21 SWITCH, TACT (FM/AM)
S212 1-762-196-21 SWITCH, TACT (6)
S213 1-762-196-21 SWITCH, TACT (5)
S214 1-762-196-21 SWITCH, TACT (4)
S215 1-762-196-21 SWITCH, TACT (7)
S216 1-762-196-21 SWITCH, TACT (8)
S217 1-762-196-21 SWITCH, TACT (9)
S218 1-762-196-21 SWITCH, TACT (FM MODE)
S219 1-762-196-21 SWITCH, TACT (VIDEO)
S220 1-762-196-21 SWITCH, TACT (CD)
S222 1-762-196-21 SWITCH, TACT (BASS BOOST)
S223 1-762-196-21 SWITCH, TACT (MUTING)
S224 1-762-196-21 SWITCH, TACT (SHIFT)
S225 1-762-196-21 SWITCH, TACT (0)
S226 1-762-196-21 SWITCH, TACT (MEMORY)
S227 1-762-196-21 SWITCH, TACT (TUNER)
S229 1-762-196-21 SWITCH, TACT (MD/TAPE)
S230 1-762-196-21 SWITCH, TACT (TV/LD)
S231 1-762-196-21 SWITCH, TACT (RDS PTY)
S234 1-762-196-21 SWITCH, TACT (SET UP)
S235 1-762-196-21 SWITCH, TACT (NAME)
S236 1-762-196-21 SWITCH, TACT (ENTER)
S237 1-762-196-21 SWITCH, TACT (+)
S238 1-762-196-21 SWITCH, TACT (–)
S239 1-762-196-21 SWITCH, TACT (EFFECT/DELAY)
S240 1-762-196-21 SWITCH, TACT (CENTER)
S241 1-762-196-21 SWITCH, TACT (REAR)
S242 1-762-196-21 SWITCH, TACT (SOUND FIELD + MODE)
DISPLAY KEY
