63
STR-DE695
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TERMINAL BOARD >
TM601 1-694-935-11 TERMINAL BOARD (8P) (SPEAKERS
FRONT A,SURROUND)
*************************************************************
A-4731-522-A POWER BOARD, COMPLETE (EXCEPT CH)
A-4731-751-A POWER BOARD, COMPLETE (CH)
***********************
< CONNECTOR >
* CNP102 1-564-518-11 PLUG, CONNECTOR 3P
< SWITCH >
S151 1-771-410-21 SWITCH, TACTILE (SPEAKERS)
S152 1-771-410-21 SWITCH, TACTILE (?/1)
*************************************************************
A-4731-527-A S-VIDEO BOARD, COMPLETE (US,CND)
A-4731-670-A S-VIDEO BOARD, COMPLETE
(EXCEPT US,CND,AEP,UK,CH)
A-4731-736-A S-VIDEO BOARD, COMPLETE (AEP,UK)
A-4731-748-A S-VIDEO BOARD, COMPLETE (CH)
************************
< CAPACITOR >
C251 1-126-947-11 ELECT 47uF 20% 35V
C252 1-164-159-11 CERAMIC 0.1uF 50V
C253 1-164-159-11 CERAMIC 0.1uF 50V
C254 1-126-947-11 ELECT 47uF 20% 35V
C255 1-164-159-11 CERAMIC 0.1uF 50V
C256 1-164-159-11 CERAMIC 0.1uF 50V
C257 1-128-817-11 CERAMIC 470PF 5% 50V
C258 1-128-805-11 CERAMIC 47PF 5% 50V
C259 1-128-805-11 CERAMIC 47PF 5% 50V
C260 1-126-964-11 ELECT 10uF 20% 50V
C261 1-164-159-11 CERAMIC 0.1uF 50V
C262 1-126-964-11 ELECT 10uF 20% 50V
C263 1-164-159-11 CERAMIC 0.1uF 50V
C265 1-128-805-11 CERAMIC 47PF 5% 50V
C266 1-128-805-11 CERAMIC 47PF 5% 50V
C267 1-128-817-11 CERAMIC 470PF 5% 50V
C268 1-126-964-11 ELECT 10uF 20% 50V
C269 1-164-159-11 CERAMIC 0.1uF 50V
C272 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT AEP,UK)
C275 1-128-817-11 CERAMIC 470PF 5% 50V
< CONNECTOR >
CNS252 1-568-442-11 SOCKET, CONNECTOR 9P
< DIODE >
D251 8-719-991-33 DIODE 1SS133T-77
D252 8-719-991-33 DIODE 1SS133T-77
< IC >
IC251 6-701-890-01 IC NJM2595D
IC252 6-701-890-01 IC NJM2595D
< CONNECTOR >
J251 1-537-943-11 CONNECTOR (DIN) 1P (MONITOR S-VIDEO OUT)
J252 1-794-937-11 CONNECTOR (DIN) 2P (DVD S-VIDEO IN,
VIDEO 2 S-VIDEO IN)
J253 1-794-937-11 CONNECTOR (DIN) 2P (VIDEO 1 S-VIDEO OUT,
VIDEO 1 S-VIDEO IN)
< JACK >
J254 1-563-330-11 JACK (CTRL A1 II) (EXCEPT AEP,UK)
< RESISTOR >
R206 1-247-804-11 CARBON 75 5% 1/4W
R251 1-247-804-11 CARBON 75 5% 1/4W
R252 1-247-804-11 CARBON 75 5% 1/4W
R253 1-247-804-11 CARBON 75 5% 1/4W
R254 1-247-804-11 CARBON 75 5% 1/4W
R255 1-247-804-11 CARBON 75 5% 1/4W
R257 1-247-804-11 CARBON 75 5% 1/4W
R258 1-247-804-11 CARBON 75 5% 1/4W
R259 1-247-804-11 CARBON 75 5% 1/4W
R260 1-247-804-11 CARBON 75 5% 1/4W
*************************************************************
A-4734-561-A SB AMP BOARD, COMPLETE (US,CND)
***********************
< CAPACITOR >
C561 1-126-963-11 ELECT 4.7uF 20% 50V
(US,CND)
C562 1-128-809-11 CERAMIC 100PF 5% 50V
(US,CND)
C563 1-106-359-00 MYLAR 0.0047uF 5% 200V
(US,CND)
C564 1-102-233-00 CERAMIC 33PF 10% 500V
(US,CND)
C565 1-107-583-11 CERAMIC 3PF 0.25PF 500V
(US,CND)
C566 1-104-665-11 ELECT 100uF 20% 10V
(US,CND)
C571 1-126-947-11 ELECT 47uF 20% 25V
(US,CND)
C573 1-162-815-11 CERAMIC 47PF 5% 500V
(US,CND)
C575 1-162-815-11 CERAMIC 47PF 5% 500V
(US,CND)
C576 1-127-876-11 CERAMIC 0.01uF 10% 50V
(US,CND)
C577 1-126-964-11 ELECT 10uF 20% 50V
(US,CND)
C578 1-128-813-11 CERAMIC 220PF 5% 50V
(US,CND)
C581 1-136-157-00 FILM 0.022uF 5% 50V
(US,CND)
< CONNECTOR >
* CN572 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P (US,CND)
< DIODE >
D575 8-719-991-33 DIODE 1SS133T-77 (US,CND)
D576 8-719-991-33 DIODE 1SS133T-77 (US,CND)
POWER SB AMPS-VIDEO
Ver 1.1
MAIN
