64
STR-DE695
< IC >
IC571 8-749-011-16 IC STK350-230 (US,CND)
< TRANSISTOR >
Q575 8-729-140-82 TRANSISTOR 2SA988-PAFAEA (US,CND)
Q576 8-729-140-82 TRANSISTOR 2SA988-PAFAEA (US,CND)
Q577 8-729-281-53 TRANSISTOR 2SC1815-GR (US,CND)
< RESISTOR >
R560 1-249-411-11 CARBON 330 5% 1/4W
(US,CND)
R561 1-249-417-11 CARBON 1K 5% 1/4W
(US,CND)
R562 1-249-439-11 CARBON 68K 5% 1/4W
(US,CND)
R565 1-249-439-11 CARBON 68K 5% 1/4W
(US,CND)
R566 1-249-421-11 CARBON 2.2K 5% 1/4W
(US,CND)
R571 1-249-421-11 CARBON 2.2K 5% 1/4W
(US,CND)
R572 1-249-425-11 CARBON 4.7K 5% 1/4W
(US,CND)
R573 1-249-405-11 CARBON 100 5% 1/4W
(US,CND)
R574 1-249-417-11 CARBON 1K 5% 1/4W
(US,CND)
R575 1-249-405-11 CARBON 100 5% 1/4W
(US,CND)
R576 1-247-850-11 CARBON 6.2K 5% 1/4W
(US,CND)
R577 1-249-425-11 CARBON 4.7K 5% 1/4W
(US,CND)
R578 1-234-572-11 ENCAPSULATED COMPONENT 0.22X2 5W
(US,CND)
R579 1-249-419-11 CARBON 1.5K 5% 1/4W
(US,CND)
R580 1-249-439-11 CARBON 68K 5% 1/4W
(US,CND)
R581 1-249-393-11 CARBON 10 5% 1/4W
(US,CND)
R583 1-249-431-11 CARBON 15K 5% 1/4W
(US,CND)
R584 1-249-431-11 CARBON 15K 5% 1/4W
(US,CND)
R585 1-249-425-11 CARBON 4.7K 5% 1/4W
(US,CND)
R586 1-249-437-11 CARBON 47K 5% 1/4W
(US,CND)
R587 1-249-437-11 CARBON 47K 5% 1/4W
(US,CND)
R588 1-249-433-11 CARBON 22K 5% 1/4W
(US,CND)
R596 1-247-843-11 CARBON 3.3K 5% 1/4W
(US,CND)
*************************************************************
1-687-162-11 SPEAKER BOARD
**************
< CAPACITOR >
CC19 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP,UK,CH,TW)
CC21 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP,UK,CH,TW)
CC23 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP,UK,CH,TW)
< CONNECTOR >
* CNP501 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P (US,CND)
CNP807 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
< DIODE >
D510 8-719-991-33 DIODE 1SS133T-77
D760 8-719-991-33 DIODE 1SS133T-77
< COIL >
L521 1-422-009-13 COIL, AIR-CORE
L571 1-422-009-13 COIL, AIR-CORE (US,CND)
< TRANSISTOR >
Q550 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q760 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R528 1-249-389-11 CARBON 4.7 5% 1/4W
R531 1-249-425-11 CARBON 4.7K 5% 1/4W
R534 1-249-389-11 CARBON 4.7 5% 1/4W
R578 1-249-389-11 CARBON 4.7 5% 1/4W
(US,CND)
R752 1-249-425-11 CARBON 4.7K 5% 1/4W
R774 1-249-389-11 CARBON 4.7 5% 1/4W
RR15 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,CH,TW)
RR16 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,CH,TW)
RR17 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,CH,TW)
< RELAY >
RY501 1-755-421-11 RELAY (12V)
RY751 1-755-421-11 RELAY (12V)
< TERMINAL BOARD >
TM501 1-694-933-11 TERMINAL BOARD (4P) (SPEAKERS
CENTER,SURROUND BACK) (US,CND)
TM501 1-694-992-11 TERMINAL BOARD (2P) (SPEAKERS
CENTER) (EXCEPT US,CND)
* TM601 1-537-240-21 TERMINAL BOARD (CHECKER PIN)
(SPEAKERS FRONT B)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SB AMP SPEAKER
Ver 1.1
