Sony STR-DE695 - Page 65

65
STR-DE695
A-4731-517-A STANDBY BOARD, COMPLETE (US,CND)
A-4731-668-A STANDBY BOARD, COMPLETE (AEP,UK,SP,MY)
A-4731-683-A STANDBY BOARD, COMPLETE (E2,E3,JE)
A-4731-688-A STANDBY BOARD, COMPLETE (AR)
A-4731-692-A STANDBY BOARD, COMPLETE (MX)
A-4731-734-A STANDBY BOARD, COMPLETE (TW)
A-4731-745-A STANDBY BOARD, COMPLETE (CH)
A-4747-418-A STANDBY BOARD, COMPLETE (AUS)
*************************
1-533-293-11 HOLDER, FUSE
< CAPACITOR >
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-164-159-11 CERAMIC 0.1uF 50V
C815 1-126-943-11 ELECT 2200uF 20% 25V
C816 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-164-159-11 CERAMIC 0.1uF 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
C922 1-164-159-11 CERAMIC 0.1uF 50V
C923 1-164-159-11 CERAMIC 0.1uF 50V
C924 1-126-959-11 ELECT 0.47uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
C951 1-126-942-61 ELECT 1000uF 20% 25V
< CONNECTOR >
CNP801 1-766-203-11 PLUG, CONNECTOR (PC BOARD) 5P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP902 1-580-843-11 PIN, CONNECTOR (POWER) 2P
CNP903 1-779-977-11 PIN, CONNECTOR 6P
CPN904 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D820 8-719-024-99 DIODE 11ES2-NTA2B
D821 8-719-024-99 DIODE 11ES2-NTA2B
D822 8-719-024-99 DIODE 11ES2-NTA2B
D823 8-719-024-99 DIODE 11ES2-NTA2B
D901 8-719-991-33 DIODE 1SS133T-77
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
D916 8-719-024-99 DIODE 11ES2-NTA2B
< EARTH TERMINAL >
* G901 1-537-738-21 TERMINAL, EARTH
< AC OUTLET >
0 J911 1-251-417-11 OUTLET, AC (1P) (AC OUTLET) (AUS)
0 J911 1-785-285-11 OUTLET, AC (1P) (AC OUTLET)
(AEP,UK,JE,SP,MY)
0 J911 1-785-834-11 OUTLET, AC (1P) (AC OUTLET)
(US,CND,E2,E3,CH,MX,TW)
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q921 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q922 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q923 8-729-140-93 TRANSISTOR 2SB733-34
< RESISTOR >
0 R810 1-243-634-00 FUSIBLE 0.22 5% 1/2W F
0 R811 1-243-634-00 FUSIBLE 0.22 5% 1/2W F
0 R901 1-219-237-11 SOLID 3.3M 20% 1/2W F
(US,CND)
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W
R904 1-249-381-11 CARBON 1 5% 1/4W
R921 1-249-437-11 CARBON 47K 5% 1/4W
R922 1-249-433-11 CARBON 22K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
R925 1-249-425-11 CARBON 4.7K 5% 1/4W
< RELAY >
0 RY901 1-755-439-11 RELAY
< TRANSFORMER >
0 T902 1-437-312-11 TRANSFORMER, POWER (US,CND,MX,TW)
0 T902 1-437-313-11 TRANSFORMER, POWER
(AEP,UK,AUS,SP,MY,CH,AR)
0 T902 1-437-314-11 TRANSFORMER, POWER (E2,E3,JE)
*************************************************************
1-687-163-11 VIDEO BOARD
************
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-934-11 ELECT 220uF 20% 16V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C220 1-126-947-11 ELECT 47uF 20% 35V
C221 1-126-934-11 ELECT 220uF 20% 16V
C223 1-164-159-11 CERAMIC 0.1uF 50V
C224 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C301 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT AEP,UK)
C302 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT AEP,UK)
C303 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT AEP,UK)
C308 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP,UK)
C309 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP,UK)
C310 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP,UK)
C311 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP,UK)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
STANDBY VIDEO
Ver 1.1
