Sony STR-DE695 - Page 66

66
STR-DE695
C312 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP,UK)
C313 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP,UK)
C317 1-126-947-11 ELECT 47uF 20% 25V
(EXCEPT AEP,UK)
C329 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT AEP,UK)
C330 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT AEP,UK)
C331 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT AEP,UK)
C332 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT AEP,UK)
C338 1-126-947-11 ELECT 47uF 20% 25V
(EXCEPT AEP,UK)
< CONNECTOR >
* CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CNP203 1-784-920-11 PIN, CONNECTOR 3P
CNS201 1-568-442-11 SOCKET, CONNECTOR 9P
CNS250 1-568-439-11 SOCKET, CONNECTOR 7P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
< IC >
IC203 6-701-890-01 IC NJM2595D
IC301 8-759-231-66 IC TC74HC4053AP (EXCEPT AEP,UK)
IC302 6-701-891-01 IC NJM2581D (EXCEPT AEP,UK)
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P (DVD VIDEO IN,
VIDEO 2 VIDEO IN,VIDEO 1 VIDEO OUT)
J201 1-815-043-11 JACK, PIN 2P (VIDEO 1 VIDEO IN,
MONITOR VIDEO OUT)
J301 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO
DVD IN,VIDEO 2 IN,MONITOR OUT)
(EXCEPT AEP,UK)
< TRANSISTOR >
Q301 8-729-116-02 TRANSISTOR BA1A4M-TP (EXCEPT AEP,UK)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R302 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R303 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R304 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R305 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R306 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R307 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R308 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R309 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT AEP,UK)
R310 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT AEP,UK)
R311 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT AEP,UK)
R312 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT AEP,UK)
R313 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT AEP,UK)
R325 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT AEP,UK)
R347 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT AEP,UK)
*************************************************************
1-687-157-11 VIDEO3 BOARD
*************
< CAPACITOR >
C293 1-164-159-11 CERAMIC 0.1uF 50V
C294 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN201 1-784-922-11 PIN, CONNECTOR 5P
< JACK >
J298 1-815-684-11 JACK, PIN 3P (VIDEO 3 INPUT)
(US,CND,AEP,UK,E2,E3,AUS,MX,AR)
J298 1-817-374-11 JACK, PIN 3P (VIDEO 3 INPUT)
(JE,SP,MY,CH,TW)
< RESISTOR >
R298 1-249-417-11 CARBON 1K 5% 1/4W
R299 1-249-417-11 CARBON 1K 5% 1/4W
< LEAD >
* W290 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
VOL BOARD
**********
< CONNECTOR >
* CNP104 1-564-518-11 PLUG, CONNECTOR 3P
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VIDEO VOLVIDEO3
Ver 1.1
