[§] AUDIO INPUT/OUTPUT section
[l] VIDEO/AUDIO INPUT/OUTPUT
section
rnJ COMPONENT VIDEO INPUTI
OUTPUT section
You can use the supplied RM-AAU021
Remote Commander
to operate the receiver
and
to control the Sony audio/video
components that the remote
is assigned to
operate (page 96).
Connects to a DVD
player, TV, satellite
tuner, etc. You can
enjoy high quality
image (page 20-
27).
Connects to a Super
Audio CD player,
CD recorder, etc.
(page 21).
Connects to a VCR,
Blu-ray disc player,
etc. (page 20-27).
VIDEO IN!
OUT* jacks
AUDIO IN!
OUT jacks
AUDIO IN!
OUT jacks
Y, PB!CB,
PRiCR IN!
OUT* jacks
AUDIO OUT Connects to a
jack subwoofer (page
18).
@YeIlOW
@White(L)
@Red(R)
@ Black
@White(L)
@ Red (R)
~Green
~(Y)
~Blue
"@ (PB!CB)
t@Red
~ (PR/CR)
* You can watch the selected input image when you
connect the MONITOR OUT or HDMI OUT jack
to a TV or projector (page 20).
