Sony STR-DN610 - Rear Panel

10
GB
D:\NORM'S JOB\SONY HA\SO0086\STR-DN610_PMRF 2\GB\GB03DES_STR-DN610-U2.fm masterpage: Left
STR-DN610
4-167-824-13(1)
* You can watch the selected input image when you
connect the HDMI TV OUT or MONITOR OUT
jack to a TV (page 20, 23).
Rear panel
LR
LR
R
L
FRONT A
CENTER SURROUND
ANTENNA
TV OUT1 NI2 NI3 NI
HDMI
ASSIGNABLE (INPUT ONLY)
ARC
TV
IN
OPTICAL
SAT/
CATV
IN
OPTICAL
DVD
IN
DIGITAL
COAXIAL
(ASSIGNABLE)
DMPORT
DC5V
0.7A MAX
P B /
C B
P R /
C R
Y
IN 3 IN 2 IN 1
MONITOR
OUT
COMPONENT VIDEO
ASSIGNABLE (INPUT ONLY)
VIDEO
IN
VIDEO
IN
VIDEO
OUT
VIDEO
IN
MONITOR
VIDEO
OUT
AUDIO
IN
AUDIO
OUT
AUDIO
IN
BD
SAT/CATV
AUDIO
IN
AUDIO
IN
SA-CD/CD/CD-R
R
VIDEO 1
L
AUDIO
IN
AUDIO
OUT
AUDIO
OUT
TV
SUBWOOFER
SPEAKERS
IMPEDANCE USE 8-16
1 21,223
5 1 4
A Audio signal section
DIGITAL INPUT/OUTPUT jacks (page 20,
23, 26, 27, 28)
HDMI IN/OUT
OPTICAL IN
COAXIAL IN
ANALOG INPUT/OUTPUT jacks (page 18,
20, 21, 26, 28, 29)
AUDIO
IN/OUT
AUDIO OUT
White (L)
Red (R)
Black
B Video signal section*
The image quality depends on the connecting
jack.
DIGITAL INPUT/OUTPUT
jacks (page 20, 23)
HDMI IN/OUT
COMPONENT VIDEO
INPUT/OUTPUT jacks (page
20, 26, 27, 28)
Y, P
B/CB, PR/CR
IN/OUT
COMPOSITE VIDEO INPUT/
OUTPUT jacks (page 20, 26,
28, 29)
VIDEO IN/OUT
High
quality
Green
(Y)
Blue
(PB/CB)
Red
(P
R/CR)
Yellow
