3232
STR-K1500
STR-K1500
-
+
-
+
CENTER
SURROUND BACK
TM501
E
1
3
R
MAIN
BOARD
CNP806
(Page 25)
M
MAIN
BOARD
CN808
(Page 25)
T
MAIN
BOARD
WP02
(Page 25)
U
MAIN
BOARD
WP03
(Page 25)
12
A
B
C
D
E
345
SPEAKER C/SB BOARD
3-17. PRINTED WIRING BOARD – SPEAKER C/SB BOARD –
:Uses unleaded solder.
• See page 15 for Circuit Boards Location.

Sony STR-K1500 - Receiver Component For Ht-ddw1500 Specifications

General

Preset Station Qty	30
Digital Sound Processor (DSP)	Yes
Frequency Response	20Hz - 20kHz
Surround Sound	Dolby Digital, DTS
Tuner Bands	FM/AM
Tuning Range	FM: 87.5 - 108 MHz, AM: 530 - 1710 kHz
Connector Type	RCA
Width	430 mm
Depth	310 mm
Height	157.5 mm
