STR-K1500
STR-K1500
3-19. PRINTED WIRING BOARDS – ADCC BOARD, VIDEO 3 BOARD –
:Uses unleaded solder.
• See page 15 for Circuit Boards Location.
MAIN
BOARD
CN506
(Page 25)
I
MAIN
BOARD
CNP503
(Page 25)
J
VIDEO
BOARD
CNP202
(Page 36)
W
IC2000
1
5
AUTO CAL MIC
L
R
AUDIO
VIDEO
VIDEO 3 IN/
PORTABLE AV IN
12
A
B
C
3456
1
1
4
4
85
(CHASSIS)

Sony STR-K1500 - Receiver Component For Ht-ddw1500 Specifications

General

Preset Station Qty	30
Digital Sound Processor (DSP)	Yes
Frequency Response	20Hz - 20kHz
Surround Sound	Dolby Digital, DTS
Tuner Bands	FM/AM
Tuning Range	FM: 87.5 - 108 MHz, AM: 530 - 1710 kHz
Connector Type	RCA
Width	430 mm
Depth	310 mm
Height	157.5 mm
