Sony STR-K1500 - Receiver Component For Ht-ddw1500 User Manual

7
STR-K1500
Rear panel
R
L
1 2 3 4
57 6
DIGITAL
VIDEO 1
IN
VIDEO 2
IN
OPTICAL
DVD
IN
COAXIAL
HDMI
DVD IN
ASSIGNABLE
VIDEO 2 IN MONITOR OUT
AM
ANTENNA
D-LIGHT
SYNC OUT
SA-CD / CD MD/TAPE
OUT
L
R
IN
IN
L
R
AUDIO IN
DVD
AUDIO IN
VIDEO 2
AUDIO IN
VIDEO 1
AUDIO OUT
L
R
VIDEO IN VIDEO IN VIDEO OUT VIDEO IN
VIDEO OUT
MONITOR
DVD
IN
VIDEO 2
IN
MONITOR
OUT
COMPONENT VIDEO
Y
ASSIGNABLE
P B /C B
/B–Y
P
R /C R
/R–Y
SUB
WOOFER
AUDIO
OUT
SURROUND FRONT
R
R
L
L
+ – + –
SURROUND BACK
CENTER
+ –
SPEAKERS
L
R
SURROUND
SUB
WOOFER
CENTER
MULTI CH IN
FRONT
A DIGITAL INPUT/OUTPUT section
OPTICAL
IN jack
Connects to a DVD
player, etc. The
COAXIAL jack
provides a better
quality of loud
sound.
COAXIAL IN
jack
HDMI IN/
MONITOR
OUT jack
a)b)
Connects to a DVD
player, or a satellite
tuner. The image
and the sound are
output to a TV or a
projector.
B VIDEO/AUDIO INPUT/OUTPUT
section
AUDIO IN/
OUT jack
Connects the video
and audio jacks of
a VCR or a DVD
player.
VIDEO IN/
OUT jack
a)
White (L)
Red (R)
Ye llow
C COMPONENT VIDEO INPUT/
OUTPUT section
COMPONENT
VIDEO
INPUT/
OUTPUT
jack
a)
Connects to a DVD
player, TV, or a
satellite tuner. You
can enjoy high
quality image.
D SPEAKER section
Connects to the
speakers.
Connects to the
sub woofers.
E AUDIO INPUT/OUTPUT section
AUDIO IN/
OUT jack
Connects to an MD
deck or CD player,
etc.
MULTI
CHANNEL
INPUT jack
Connects to a
Super Audio CD
player or DVD
player which has
an analog audio
jack for 5.1
channel sound.
Green
Blue
Red
White (L)
Red (R)
White (L)
Red (R)
Black

Sony STR-K1500 - Receiver Component For Ht-ddw1500 Specifications

General

Preset Station Qty	30
Digital Sound Processor (DSP)	Yes
Frequency Response	20Hz - 20kHz
Surround Sound	Dolby Digital, DTS
Tuner Bands	FM/AM
Tuning Range	FM: 87.5 - 108 MHz, AM: 530 - 1710 kHz
Connector Type	RCA
Width	430 mm
Depth	310 mm
Height	157.5 mm
