STR-K740P/K840P
Inputs (Digital)
DVD/LD (Coaxial)
VIDEO 2 (Optical)
Outputs
MD/TAPE (OUT),
VIDEO 1
(AUDIO OUT)
SUB WOOFER
Tone
Gain levels: ±6 dB, 1 dB step
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna terminals 75 ohms, unbalanced
Intermediate Frequency
10.7 MHz
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo:
38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code U, CA
With 10-kHz tuning scale: 530 – 1710 kHz
6)
With 9-kHz tuning scale: 531 – 1710 kHz
6)
Models of area code E, AR, MX
With 10-kHz tuning scale: 530 – 1610 kHz
6)
With 9-kHz tuning scale: 531 – 1602 kHz
6)
Models of area code MY, SP, CEL, CEK
With 9-kHz tuning scale: 531 – 1602 kHz
Antenna Loop antenna
Intermediate Frequency
450 kHz
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
6) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. Hold down PRESET TUNING + and
press . All preset stations will be erased when
you change the tuning scale. To reset the scale to
10 kHz (or 9 kHz), repeat the procedure.
Video section
Inputs
Video: 1 Vp-p, 75 ohms
Outputs
Video: 1 Vp-p, 75 ohms
Sensitivity: –
Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Sensitivity: –
Impedance: –
S/N: 100 dB
(A, 20 kHz LPF)
Voltage: 250 mV
Impedance: 10 kilohms
Voltage: 2 V
Impedance: 1 kilohms
General
Power requirements
Area code Power requirements
U, CA, MX 120 V AC, 60 Hz
CEL, CEK 230 V AC, 50/60 Hz
MY, SP, AR 220 – 230 V AC, 50/60 Hz
E 120/220/240 V AC, 50/60 Hz
Power consumption
Area code Power consumption
U, MX STR-K840P: 210 W
STR-K740P: 180 W
CA STR-K840P: 300 VA
STR-K740P: 260 VA
CEL, CEK, MY, SP, STR-K840P: 180 W
E, AR STR-K740P: 155 W
Power consumption (during standby mode)
0.5 W
Dimensions 430 145 298 mm
(16 7/8 5 6/8 11 6/8
inches) including
projecting parts and
controls
Mass (Approx.) 7.0 kg (15 lb 7 oz)
Design and specifications are subject to change
without notice.
Frequency response
MULTI CH IN
3)
, CD,
MD/TAPE, DVD/LD,
VIDEO 1, 2
Inputs (Analog)
MULTI CH IN
3)
, CD,
MD/TAPE, DVD/LD,
VIDEO 1, 2
3) HT-DDW840 only
4) INPUT SHORT (with sound field and tone
bypassed).
5) Weighted network, input level.
10 Hz – 50 kHz
+0.5/–2 dB (with sound
field, and tone bypassed)
Sensitivity: 250 mV
Impedance: 50 kilohms
S/N
4)
: 96 dB
(A, 250 mV
5)
)
• Abbreviation
U : US model.
CA : Canadian model.
CEL : AEP model.
CEK : UK model.
SP : Singapore model. (Malaysia model included.)
MX : Mexican model.
MY : Malaysia model.
AR : Argentine model.
