30
STR-K740P/K840P
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• CAPACITORS:
uF: µF
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
MX : Mexican model
AR : Argentine model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
AC SELECT
1-683-761-11 AC SELECT BOARD (K740P:E/K840P:E)
*******************************
< CONNECTOR >
* CNP910 1-564-687-11 PIN, CONNECTOR 3P (K740P:E/K840P:E)
< SWITCH >
0S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (K740P:E/K840P:E)
**************************************************************
A-4728-360-A DIGITAL BOARD, COMPLETE (K740P:US,CND)
*************************************
A-4727-964-A DIGITAL BOARD, COMPLETE (K840P:US,CND)
*************************************
A-4727-980-A DIGITAL BOARD, COMPLETE (K840P:AEP,UK)
************************************
A-4727-974-A DIGITAL BOARD, COMPLETE (K840P:E,MX)
***********************************
A-4727-970-A DIGITAL BOARD, COMPLETE (K840P:MY,SP,AR)
**************************************
A-4728-363-A DIGITAL BOARD, COMPLETE (K740P:MY,SP)
************************************
A-4728-365-A DIGITAL BOARD, COMPLETE (K740P:E)
********************************
A-4728-368-A DIGITAL BOARD, COMPLETE (K740P:AEP,UK)
*************************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-126-947-11 ELECT 47uF 20.00% 16V
C1103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1105 1-126-947-11 ELECT 47uF 20.00% 16V
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C1110 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C1111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1114 1-162-905-11 CERAMIC CHIP 1PF 25.00% 50V
C1115 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1116 1-126-935-11 ELECT 470uF 20.00% 16V
C1117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C1119 1-126-965-91 ELECT 22uF 20.00% 50V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1126 1-126-964-11 ELECT 10uF 20.00% 50V
C1127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C1130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1211 1-126-964-11 ELECT 10uF 20.00% 50V
C1212 1-126-964-11 ELECT 10uF 20.00% 50V
C1213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1220 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1229 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1501 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1502 1-126-965-91 ELECT 22uF 20.00% 50V
C1503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1504 1-126-964-11 ELECT 10uF 20.00% 50V
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-126-935-11 ELECT 470uF 20.00% 16V
C1507 1-126-964-11 ELECT 10uF 20.00% 50V
C1508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1510 1-126-947-11 ELECT 47uF 20.00% 16V
C1512 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
DIGITAL
