Sony STR-K740P - Digital Display

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
33
STR-K740P/K840P
DIGITAL
DISPLAY
R1640 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1641 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1642 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1643 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1644 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1645 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1646 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1647 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1648 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1649 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1650 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1651 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1654 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1655 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1656 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1657 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1658 1-216-809-11 METAL CHIP 100 5% 1/16W
R1659 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1661 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1662 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R1663 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R1666 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1668 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R1669 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1670 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1673 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1674 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1676 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1677 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1678 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1679 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1682 1-216-845-11 METAL CHIP 100K 5% 1/16W
R1684 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1685 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1686 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1687 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1688 1-216-864-11 METAL CHIP 0 5% 1/16W
R1689 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1690 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1691 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1694 1-216-821-11 METAL CHIP 1K 5% 1/16W
R1697 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(K840P)
R1697 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(K740P)
R1698 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1699 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R1703 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1704 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1706 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1707 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1708 1-216-833-11 METAL CHIP 10K 5% 1/16W
R1709 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VIBRATOR >
X1101 1-781-465-21 VIBRATOR, CRYSTAL 12.288MHz
X1201 1-795-297-21 VIBRATOR, CERAMIC 13.59MHz
X1601 1-795-318-11 OSCILLATOR, CERAMIC 20MHz
**************************************************************
A-4728-362-A DISPLAY BOARD, COMPLETE (K740P)
*******************************
A-4727-966-A DISPLAY BOARD, COMPLETE (K840P)
*******************************
* 3-386-245-13 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
(K840P)
C105 1-126-795-11 ELECT 10uF 20.00% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-128-809-11 CERAMIC 100PF 5% 50V
C111 1-128-809-11 CERAMIC 100PF 5% 50V
C112 1-128-809-11 CERAMIC 100PF 5% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-795-11 ELECT 10uF 20.00% 50V
C132 1-128-813-11 CERAMIC 220PF 5% 50V
C133 1-128-813-11 CERAMIC 220PF 5% 50V
C134 1-128-813-11 CERAMIC 220PF 5% 50V
C135 1-128-813-11 CERAMIC 220PF 5% 50V
C136 1-128-813-11 CERAMIC 220PF 5% 50V
C137 1-128-813-11 CERAMIC 220PF 5% 50V
C138 1-128-813-11 CERAMIC 220PF 5% 50V
C139 1-128-813-11 CERAMIC 220PF 5% 50V
C140 1-128-813-11 CERAMIC 220PF 5% 50V
C141 1-128-813-11 CERAMIC 220PF 5% 50V
C142 1-128-813-11 CERAMIC 220PF 5% 50V
C143 1-128-813-11 CERAMIC 220PF 5% 50V
C144 1-164-159-11 CERAMIC 0.1uF 50V
C145 1-164-159-11 CERAMIC 0.1uF 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-795-11 ELECT 10uF 20.00% 50V
< DIODE >
D100 8-719-075-59 DIODE SELS5B23C-TP15
(Digital Cinema Sound)
D102 8-719-084-07 DIODE SEL5E20CTP15
(MULTI CHANNEL DECODING) (K840P)
D103 8-719-046-39 DIODE SEL5821A-TP15 (A.F.D.)
D104 8-719-046-39 DIODE SEL5821A-TP15 (2CH)
D105 8-719-046-39 DIODE SEL5821A-TP15 (MODE)
D111 8-719-046-39 DIODE SEL5821A-TP15 (LEVEL)
D112 8-719-046-39 DIODE SEL5821A-TP15 (SURR)
D113 8-719-046-39 DIODE SEL5821A-TP15 (SET UP)
D114 8-719-046-39 DIODE SEL5821A-TP15 (NAME)
< FILTER >
FL101 1-518-718-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-036-90 IC MC74ACT08N
IC102 6-600-055-01 IC GP1UD27SXK (g)
