Sony STR-K740P - Page 35

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
35
STR-K740P/K840P
R168 1-249-409-11 CARBON 220 5% 1/4W F
R169 1-249-409-11 CARBON 220 5% 1/4W F
R170 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-249-429-11 CARBON 10K 5% 1/4W
(K840P)
0 R198 1-249-381-11 CARBON 1 5% 1/4W F
0 R199 1-249-381-11 CARBON 1 5% 1/4W F
< VARIABLE RESISTOR >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (PRESET/PTY SELECT –)
S101 1-771-410-21 SWITCH, TACTILE (TUNING –)
S102 1-771-410-21 SWITCH, TACTILE (NAME)
S103 1-771-410-21 SWITCH, TACTILE (ENTER)
S104 1-771-410-21 SWITCH, TACTILE (LEVEL)
S105 1-771-410-21 SWITCH, TACTILE (SURR)
S106 1-771-410-21 SWITCH, TACTILE (MENU –)
S107 1-771-410-21 SWITCH, TACTILE (SET UP)
S108 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S109 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S110 1-771-410-21 SWITCH, TACTILE (MUTING)
S111 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S112 1-771-410-21 SWITCH, TACTILE (TREBLE +)
S113 1-771-410-21 SWITCH, TACTILE (MULTI CH IN)
S114 1-771-410-21 SWITCH, TACTILE (CD)
S115 1-771-410-21 SWITCH, TACTILE (TUNER)
S116 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S117 1-771-410-21 SWITCH, TACTILE (BASS –)
S118 1-771-410-21 SWITCH, TACTILE (MODE)
S119 1-771-410-21 SWITCH, TACTILE (PRESET/PTY SELECT +)
S120 1-771-410-21 SWITCH, TACTILE (FM MODE) (AEP, UK)
S120 1-771-410-21 SWITCH, TACTILE (FM) (EXCEPT AEP, UK)
S121 1-771-410-21 SWITCH, TACTILE (SHIFT)
S122 1-771-410-21 SWITCH, TACTILE (PTY)
S123 1-771-410-21 SWITCH, TACTILE (MENU <)
S124 1-771-410-21 SWITCH, TACTILE (MENU >)
S125 1-771-410-21 SWITCH, TACTILE (FM/AM) (AEP, UK)
S125 1-771-410-21 SWITCH, TACTILE (AM) (EXCEPT AEP, UK)
S126 1-771-410-21 SWITCH, TACTILE (MEMORY)
S127 1-771-410-21 SWITCH, TACTILE (TUNING +)
S128 1-771-410-21 SWITCH, TACTILE (MENU +)
S130 1-771-410-21 SWITCH, TACTILE (TREBLE –)
S131 1-771-410-21 SWITCH, TACTILE (DVD/LD)
S132 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO C)
S133 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO B)
S134 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO A)
S135 1-771-410-21 SWITCH, TACTILE (BASS +)
S136 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S137 1-771-410-21 SWITCH, TACTILE (2CH)
**************************************************************
1-683-763-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-314-21 JACK (PHONES)
**************************************************************
A-4727-963-A MAIN BOARD, COMPLETE (K840P:US,CND)
***********************************
A-4727-978-A MAIN BOARD, COMPLETE (K840P:AEP,UK)
***********************************
A-4727-967-A MAIN BOARD, COMPLETE
(K840P:E,MY,SP,AR,MX)
***********************************
A-4728-583-A MAIN BOARD, COMPLETE (K740P:E,MY,SP)
***********************************
A-4728-367-A MAIN BOARD, COMPLETE (K740P:AEP,UK)
***********************************
A-4728-359-A MAIN BOARD, COMPLETE (K740P:US,CND)
***********************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-161-494-00 CERAMIC 0.022uF 25V
C372 1-161-494-00 CERAMIC 0.022uF 25V
C373 1-161-494-00 CERAMIC 0.022uF 25V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-161-494-00 CERAMIC 0.022uF 25V
C376 1-161-494-00 CERAMIC 0.022uF 25V
C400 1-128-825-11 CERAMIC 2200PF 5% 50V
C402 1-126-964-11 ELECT 10uF 20.00% 50V
C404 1-126-964-11 ELECT 10uF 20.00% 50V
C405 1-126-964-11 ELECT 10uF 20.00% 50V
C406 1-126-964-11 ELECT 10uF 20.00% 50V
C407 1-126-964-11 ELECT 10uF 20.00% 50V
C408 1-126-964-11 ELECT 10uF 20.00% 50V
C409 1-126-964-11 ELECT 10uF 20.00% 50V
C411 1-126-961-11 ELECT 2.2uF 20.00% 50V
C412 1-126-961-11 ELECT 2.2uF 20.00% 50V
C413 1-126-964-11 ELECT 10uF 20.00% 50V
C414 1-126-964-11 ELECT 10uF 20.00% 50V
C415 1-126-964-11 ELECT 10uF 20.00% 50V
C416 1-126-964-11 ELECT 10uF 20.00% 50V
C417 1-126-964-11 ELECT 10uF 20.00% 50V
C418 1-126-964-11 ELECT 10uF 20.00% 50V
C419 1-126-964-11 ELECT 10uF 20.00% 50V
C431 1-126-961-11 ELECT 2.2uF 20.00% 50V
C432 1-126-961-11 ELECT 2.2uF 20.00% 50V
DISPLAY HEADPHONE MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
