Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
42
STR-K740P/K840P
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q921 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
< RESISTOR >
0R810 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R811 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R812 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R901 1-219-237-91 SOLID 3.3M 20% 1/2W
(K740P:US,CND/K840P:US,CND)
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R904 1-249-381-11 CARBON 1 5% 1/4W F
R921 1-249-425-11 CARBON 4.7K 5% 1/4W F
R922 1-249-425-11 CARBON 4.7K 5% 1/4W F
R923 1-249-425-11 CARBON 4.7K 5% 1/4W F
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T902 1-435-436-11 TRANSFORMER, POWER
(K740P:US,CND/K840P:US,CND,MX)
0T902 1-435-434-11 TRANSFORMER, POWER (K740P:E/K840P:E)
0T902 1-435-435-11 TRANSFORMER, POWER
(K740P:AEP,UK,MY,SP/K840P:AEP,UK,MY,SP,AR)
**************************************************************
A-4727-968-A VIDEO BOARD, COMPLETE
(K740P:AEP,UK,E,MY,SP/K840P:AEP,UK,E,MY,SP,AR)
**************************************
A-4727-815-A VIDEO BOARD, COMPLETE
(K740P:CND,US/K840P:CND,US,MX)
**************************************
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20.00% 50V
C207 1-126-960-11 ELECT 1uF 20.00% 50V
C208 1-126-960-11 ELECT 1uF 20.00% 50V
C210 1-126-964-11 ELECT 10uF 20.00% 50V
C213 1-126-964-11 ELECT 10uF 20.00% 50V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 2200PF 5% 50V
C249 1-128-825-11 CERAMIC 2200PF 5% 50V
C809 1-104-665-11 ELECT 100uF 20.00% 10V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C827 1-126-947-11 ELECT 47uF 20.00% 25V
< CONNECTOR >
CNP156 1-784-921-11 PIN, CONNECTOR 4P
CNS150 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D203 8-719-911-19 DIODE 1SS133T-72
D204 8-719-911-19 DIODE 1SS133T-72
D833 8-719-043-76 DIODE AK04V1
< IC >
IC103 6-701-890-01 IC NJM2595D
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-039-69 IC uPC7805AHF
IC807 8-759-231-53 IC M5F7805L
IC807 8-759-701-75 IC NJM7805FA
< JACK >
J200 1-770-337-11 JACK, PIN 3P
(VIDEO 1 OUT, VIDEO 2 IN, DVD/LD IN)
J201 1-695-317-11 JACK, PIN 2P (MONITOR OUT, VIDEO 1 IN)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
STANDBY VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
