Sony STR-K890 - Page 57

57
STR-K890
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TM603 1-780-451-11 BANANA-PUSH TERMINAL BOARD (4P)
(SURROUND BACK,CENTER)
*************************************************************
POWER KEY BOARD
****************
< CONNECTOR >
* CN103 1-691-670-11 CONNECTOR, BOARD TO BOARD 5P
< RESISTOR >
R111 1-249-415-11 CARBON 680 5% 1/4W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (?/1)
S115 1-771-410-21 SWITCH, TACTILE (SPEAKERS)
*************************************************************
STANDBY BOARD
**************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C913 1-127-888-11 CERAMIC 0.1uF 10% 50V
C914 1-127-888-11 CERAMIC 0.1uF 10% 50V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-127-888-11 CERAMIC 0.1uF 10% 50V
C921 1-127-888-11 CERAMIC 0.1uF 10% 50V
C924 1-126-960-11 ELECT 1uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
< CONNECTOR >
* CNP802 1-564-509-11 PLUG, CONNECTOR 6P
* CNP804 1-564-506-11 PLUG, CONNECTOR 3P
* CNP805 1-564-506-11 PLUG, CONNECTOR 3P
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP902 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP903 1-564-508-11 PLUG, CONNECTOR 5P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
0 D920 6-500-522-11 DIODE 10EDB40-TA2B5
0 D921 6-500-522-11 DIODE 10EDB40-TA2B5
0 D922 6-500-522-11 DIODE 10EDB40-TA2B5
0 D923 6-500-522-11 DIODE 10EDB40-TA2B5
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q921 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
0 R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R811 1-243-634-91 FUSIBLE 0.22 5% 1/2W
R902 1-247-871-91 CARBON 47K 5% 1/4W
R903 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R904 1-249-381-11 CARBON 1 5% 1/4W F
R921 1-247-871-91 CARBON 47K 5% 1/4W
R922 1-247-863-91 CARBON 22K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-541-11 RELAY
< TRANSFORMER >
0 T902 1-443-517-11 POWER TRANSFORMER
*************************************************************
VIDEO BOARD
************
< CAPACITOR >
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-947-11 ELECT 47uF 20% 35V
C213 1-126-947-11 ELECT 47uF 20% 35V
C214 1-127-888-11 CERAMIC 0.1uF 10% 50V
C215 1-127-888-11 CERAMIC 0.1uF 10% 50V
C220 1-126-947-11 ELECT 47uF 20% 35V
C221 1-126-947-11 ELECT 47uF 20% 35V
C223 1-135-799-11 CERAMIC 0.47uF 50V
C224 1-135-799-11 CERAMIC 0.47uF 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-964-11 ELECT 10uF 20% 50V
C316 1-126-964-11 ELECT 10uF 20% 50V
C330 1-127-888-11 CERAMIC 0.1uF 10% 50V
C331 1-127-888-11 CERAMIC 0.1uF 10% 50V
C337 1-126-947-11 ELECT 47uF 20% 35V
C338 1-126-947-11 ELECT 47uF 20% 35V
C341 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CNP203 1-564-507-11 PLUG, CONNECTOR 4P
CNS207 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
POWER KEYMAIN STANDBY VIDEO
