Sony STR-KM22 - Chassis Section

66
STR-KM22/KM55/KM77
6-4. CHASSIS SECTION
* 151 3-703-150-11 CLAMP (KM55, KM77)
152 4-977-358-01 CUSHION
153 4-249-675-02 +BV SUMITITE S 4X6 ROUND
0
T901 1-697-350-11 POWER TRANSFORMER (MAIN)
(KM22: SAF, SP, AR, TH)
0
T901 1-697-353-11 POWER TRANSFORMER (MAIN) (KM22: E51, EA)
0
T901 1-697-356-11 POWER TRANSFORMER (MAIN)
(KM55: E51, EA/KM77: E51)
0
T901 1-697-357-11 POWER TRANSFORMER (MAIN)
(KM55: SAF, AR, TH, E12/KM77: SAF, SP, AR, AUS)
0
M1 1-855-006-11 FAN, DC (KM55, KM77)
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
#1
#1
153
153
not supplied
#1
not supplied
M1
#1
#1
#1
151
151
T901
heatsink section
not supplied
153
T901
not supplied
not
supplied
not
supplied
not supplied
(SUB
RECTIFIER
board)
not supplied
152
152
#1
#1
#1
not supplied
not supplied
(KM55, KM77)
(KM22)
(KM55, KM77)
F
F
F
G
G
G
H
H
I
I
I
H
Ver. 1.1
