STR-KM5/KM7
2
SAFETY-RELATED COMPONENT WARNING!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
Design and specifi cations are subject to change without notice.
• Abbreviation
E12 : 220 - 240V AC area in E model
E51 : Chilean and Peruvian models
AR : Argentina model
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
Ver. 1.5
Inputs
Analog Sensitivity: 800 mV/
50 kilohms
Digital (Coaxial) Impedance: 75 ohms
Outputs (Analog)
AUDIO OUT Voltage: 800 mV/
1 kilohm
Tone
Gain levels ±6 dB, 1 dB step
Reproduction frequency range:
28 Hz – 20,000 Hz
FM tuner section
Tuning range 87.5 MHz – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Tuning range
Antenna (aerial) Loop antenna (aerial)
Video section
(HT-M7/HT-M5)
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B: 0.7 Vp-p, 75 ohms
P
R: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
USB section
(except SAF, AR)
Supported bit rate* MP3 (MPEG 1 Audio
Layer-3):
32 kbps – 320 kbps, VBR
WMA: 48 kbps – 192 kbps
AAC: 48 kbps – 320 kbps
Area Tuning scale
10 kHz step 9 kHz step
USA, E51, AR 530 kHz –
1,710 kHz
531 kHz –
1,710 kHz
EA, SAF, AUS,
TH, E12, SP
– 531 kHz –
1,602 kHz
Supported USB device
Mass Storage Class
Maximum current 500 mA
following conditions:
240 V AC, 50 Hz
3)
Measured under the
4)
Reference power output for front, center, surround
speakers and subwoofers. Depending on the sound
field settings and the source, there may be no
sound output.
Area Power requirements
USA 120 V AC, 60 Hz
SAF, E51, E12
EA
AR, TH
127 V AC, 60 Hz
230 V AC, 50 Hz
Sampling frequencies*
MP3 (MPEG 1 Audio
Layer-3): 32 kHz/
44.1 kHz/48 kHz
WMA: 44.1 kHz
AAC: 44.1 kHz
* Compatibility with all encoding/writing
software, recording devices and recording
media cannot be guaranteed.
Transfer speed Full-speed
General
Power requirements
Area Power requirements
Power consumption (during standby mode)
0.3 W (When
“CTRL.HDMI” is set to
“CTRL OFF”)
Dimensions (width/height/depth) (Approx.)
430 mm × 178 mm ×
336 mm
(17 in × 7
1
/8 in ×
13
1
/4 in)
SAF, TH, SP 230 V AC – 240 V AC,
50/60 Hz
E51 120/220/240 V AC,
50/60 Hz
AR 220 V AC – 230 V AC,
50/60 Hz
EA 120 V AC – 127/220/230 V
AC – 240 V AC, 50/60 Hz
AUS 230 V AC, 50 Hz
E12 220 V AC – 240 V AC,
50/60 Hz
Power consumption 185 W (STR-KM7)
175 W (STR-KM5)
including projecting parts
and controls
Mass (Approx.)
(STR-KM7/STR-KM5)
10.2 kg (22 lb 8 oz)
USA 120 V AC, 60 Hz
