63
STR-KM5/KM7
SECTION 7
ELECTRICAL PARTS LIST
A-1851-631-A DCDC BOARD, COMPLETE
*********************
< CAPACITOR >
C1500 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1501 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C1502 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C1503 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C1504 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1505 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1506 1-128-954-11 ELECT 1000uF 20% 25V
C1507 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C1508 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C1509 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1510 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1511 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1512 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1529 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C1600 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C1601 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C1602 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C1603 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C1604 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1605 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1606 1-128-954-11 ELECT 1000uF 20% 25V
C1607 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C1608 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C1609 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1610 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1611 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C1612 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1629 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C1630 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN1500 1-842-648-11 CONNECTOR, BOARD TO BOARD 9P
CN1501 1-564-506-11 PLUG, CONNECTOR 3P
CN1502 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN1503 1-817-097-21 PIN, CONNECTOR (1.5MM) (SMD) 13P
< DIODE >
D1500 6-501-361-01 DIODE RB051LA-40TR
D1600 6-501-361-01 DIODE RB051LA-40TR
< IC >
IC1500 6-716-575-01 IC TPS54331GDR
IC1600
6-716-575-01 IC TPS54331GDR
< COIL >
L1500 1-424-918-21 INDUCTOR 10uH
L1501 1-424-918-21 INDUCTOR 10uH
L1600 1-424-918-21 INDUCTOR 10uH
L1601 1-424-918-21 INDUCTOR 10uH
< RESISTOR >
R1500 1-218-983-11 METAL CHIP 330K 5% 1/16W
R1501 1-218-976-11 METAL CHIP 82K 5% 1/16W
R1502 1-218-979-11 METAL CHIP 150K 5% 1/16W
R1503 1-218-990-81 SHORT CHIP 0
R1504 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1505 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R1506 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R1512 1-216-801-11 METAL CHIP 22 5% 1/10W
R1600 1-218-983-11 METAL CHIP 330K 5% 1/16W
R1601 1-218-976-11 METAL CHIP 82K 5% 1/16W
R1602 1-218-975-11 METAL CHIP 68K 5% 1/16W
R1603 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R1604 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1605 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R1612 1-216-801-11 METAL CHIP 22 5% 1/10W
*************************************************************
A-2044-508-A DIGITAL AUDIO BOARD, COMPLETE
(for SERVICE) (KM7)
A-2044-510-A DIGITAL AUDIO BOARD, COMPLETE
(for SERVICE) (KM5)
**********************
< CAPACITOR >
C2001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2011 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2013 1-112-791-11 ELECT CHIP 100uF 20% 16V
C2021 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2022 1-112-794-11 ELECT CHIP 470uF 20% 16V
C2023 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2069 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2070 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
E12 : 220 - 240V AC area in E model
E51 : Chilean and Peruvian models
AR : Argentina model
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
DCDC
DIGITAL AUDIO
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Ver. 1.6
